RJ45 With Integrated Magnetics SI-53019-F Connector 10/100BT

Name: RJ45 With Integrated Magnetics SI-53019-F Connector 10/100BT
Brand: LINK-PP
SKU: SI-53019-F
Rating: 4.9 (146 reviews)

Product Details

Place of Origin: GuangDong, China

Brand Name: LINK-PP

Certification: UL,ROHS,Reach,ISO

Model Number: SI-53019-F

Payment & Shipping Terms

Minimum Order Quantity: 50/500/1000

Price: Supportive & Competitive

Packaging Details: Tray & Carton&Reel

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 3000000/Month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                stacked rj45 connectors, rj45 magnetic jack


Bel PN:	SI-53019-F	Made In China:	LPJK0012AHNL
Family:	10/100Mbps	Category:	Rj-45 Magjack
Orientation:	Up	Samples:	Active

Bel PN:	SI-53019-F
Made In China:	LPJK0012AHNL
Family:	10/100Mbps
Category:	Rj-45 Magjack
Orientation:	Up
Samples:	Active

RJ45 With Integrated Magnetics SI-53019-F Connector 10/100BT

SI-53019-F BelJack

Trader Part Number

SI-53019-F

Price Break	Unit Price	Extended Price
1-5	A	-
10-50	B	-
100-500	C-1	-
1,000-2,500	Supportive	-
5,000	Dynamic	Dynamic
10,000	Dynamic	Dynamic
50,000	Negotiable	Negotiable
100,000	Negotiable	Negotiable
500,000	Negotiable	Negotiable

Made in China

LPJK0012AHNL

Manufacturer

LINK-PP China

Description

Rj-45 Integrated Transformers

Documents Available

PDF/3D/Step/IGS/Price/Cross

Quantity Available

2,000 PCS or 4 weeks

SI-53019-F Electrical Specifications @25℃
1.OCL: 350uH MIN
@ 100KHz/100mVrms 8mA DC Bias
2.Turns Ratio:
TX=1CT:1 RX=1CT:1
3.Insertion Loss:
1～100MHz: -1.0dB MAX
4.Return Loss(dB MIN):
1～30MHz: -18
30～60MHz: -[18+20LOG(F/30MHz)]
60～80MHz: -12
5.Crosstalk(TX - RX):
0.5～1MHz: -70 dB MIN
10MHz: -50 dB MIN
30MHz: -45 dB MIN
50MHz: -40 dB MIN
100MHz: -35 dB MIN
6.CM To CM REJ:
0.1～1MHz: -70 dB MIN
10MHz: -47 dB MIN
30MHz: -42 dB MIN
60MHz: -37 dB MIN
100MHz: -30 dB MIN
7.CM To DM REJ:
0.1～1MHz: -70 dB MIN
10MHz: -60 dB MIN
30MHz: -50 dB MIN
60MHz: -45 dB MIN
100MHz: -40 dB MIN
8.Hipot:1500Vrms
9.Operating Temperature: 0℃～70℃.

RJ45 With Integrated Magnetics SI-53019-F Connector 10/100BT 0
