Belfuse SI-50164-F Circuit Board Rj45 Connector 10/100base-t Ethernet

Name: Belfuse SI-50164-F Circuit Board Rj45 Connector 10/100base-t Ethernet
Brand: LINK-PP
SKU: SI-50164-F
Rating: 4.6 (149 reviews)

Product Details

Place of Origin: China

Brand Name: LINK-PP

Certification: UL,ROHS,Reach,ISO

Model Number: SI-50164-F

Payment & Shipping Terms

Minimum Order Quantity: 50/500/1000

Price: Supportive

Packaging Details: 50pcs/tray,1200pcs/carton

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 4600K.PCS/Month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                rj45 with magnetics, rj45 magnetic jack


Midcom PN:	SI-50164-F	Made In China:	SM-LPJ1011AWNL
Family:	10/100Mbps	Category:	Rj45 With Led
Orientation:	Up	Samples:	Active

Midcom PN:	SI-50164-F
Made In China:	SM-LPJ1011AWNL
Family:	10/100Mbps
Category:	Rj45 With Led
Orientation:	Up
Samples:	Active

Belfuse SI-50164-F Circuit Board Rj45 Connector 10/100base-t Ethernet

SI-50164-F BelJack

Trader Part Number

SI-50164-F

Price Break	Unit Price	Extended Price
1-5	A	-
10-50	B	-
100-500	C-1	-
1,000-2,500	Supportive	-
5,000	Dynamic	Dynamic
10,000	Dynamic	Dynamic
50,000	Negotiable	Negotiable
100,000	Negotiable	Negotiable
500,000	Negotiable	Negotiable

Made in China

SM-LPJ1011AWNL

Manufacturer

LINK-PP China

Description

Rj-45 Integrated Transformers

Documents Available

PDF/3D/Step/IGS/Price/Cross

Quantity Available

2,000 PCS or 4 weeks

SI-50164-F Electrical Specifications @25℃
TEST NOTES(25±5℃)
1.TR:(100KHZ,100mV);
TX=1CT:1CT ±3% RX=1CT:1CT ±3%P

2.LX:(100KHZ,100mV,8mA,DC Bias)
PINS:(P1,P3),(P4,P6)=350uH MIN
3.HIPOT:
PINS(P1,P2,P3)TO (J1,J2)=1500V
PINS(P4,P5,P6)TO (J3,J6)=1500V
4.INSERTION LOSS:
-1.0dB MAX @ 1.0MHz TO 65MHz
5.RETURN LOSS:
-20dB MIN @ 1MHz TO 10MHz
-16dB MIN @ 10MHz TO 30MHz
-12dB MIN @ 30MHz TO 60MHz
-10dB MIN @ 60MHz TO 100MHz
6.CROSS TALK:
-40dB MIN @ 1MHz TO 30MHz
-35dB MIN @ 30MHz TO 60MHz
-30dB MIN @ 60MHz TO 100MHz
7.COMMON TO COMMON MODE REJECTION:
-30dB MIN @1MHz TO 50MHz
-20dB MIN @50MHz TO 150MHz
8.Operating Temperature: 0℃～70℃.
