Home > products > Magnetic RJ45 Jack > Magnetic RJ45 Jack SI-60107-F Modular Jack 10/100BT Shielded Right Angle

Magnetic RJ45 Jack SI-60107-F Modular Jack 10/100BT Shielded Right Angle

Product Details

Place of Origin: China

Brand Name: LINK-PP

Certification: UL,ROHS,Reach,ISO

Model Number: SI-60107-F

Payment & Shipping Terms

Minimum Order Quantity: 50/500/1000

Price: Supportive

Packaging Details: 50pcs/tray,1200pcs/carton

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 4600K.PCS/Month

Get Best Price
Highlight:

stacked rj45 connectors

,

rj45 magnetic jack

Midcom PN:
SI-60107-F
Made In China:
SM-LPJ0024ABNL
Family:
10/100BT
Category:
Rj45 Female Port
Orientation:
Down
Samples:
3-5 PCS Free
Midcom PN:
SI-60107-F
Made In China:
SM-LPJ0024ABNL
Family:
10/100BT
Category:
Rj45 Female Port
Orientation:
Down
Samples:
3-5 PCS Free
Magnetic RJ45 Jack SI-60107-F Modular Jack 10/100BT Shielded Right Angle

Magnetic RJ45 Jack SI-60107-F Modular Jack 10/100BT Shielded Right Angle



Belfuse SI-60107-F
Trader Part Number
SI-60107-F
Price Break
Unit Price
Extended Price
1-5
A
-
10-50
B
-
100-500
C-1
-
1,000-2,500
Supportive
-
5,000
Dynamic
Dynamic
10,000
Dynamic
Dynamic
50,000
 Negotiable
Negotiable
100,000
 Negotiable
Negotiable
500,000
 Negotiable
Negotiable
Made in China
SM-LPJ0024ABNL
Manufacturer
LINK-PP China
Description
Rj-45 Integrated Transformers
Documents Available
PDF/3D/Step/IGS/Price/Cross
Quantity Available
2,000 PCS or 4 weeks



SI-60107-F ELECTRICAL SPECFICATIONS: @25℃ELECTRICAL
1.Turn Ratio(±2%):
  TX=1CT:1      RX=1CT:1CT
2.Inductance OCL:
  350uH MIN @ 100KHz,0.1V,8mA DC Bias
3.Insertion Loss:
  -1.0dB MAX @ 1-65MHz
4.Return Loss:
  -20dB MIN @ 1-10MHz
  -16dB MIN @ 10-30MHz
  -12dB MIN @ 30-60MHz
  -10dB MIN @ 60-100MHz
5.Cross talk:
  -40dB MIN @ 1-30MHz
  -35dB MIN @ 30-60MHz
  -30dB MIN @ 60-100MHz
6.Common Mode Rejection:
  -30dB MIN @ 1-50MHz
  -20dB MIN @ 50-150MHz
7.Hipot Test: 1500Vrms MIN
8.Operating Temperature Range: 0℃ TO 70℃.
