RJMG168007101GR Rjmag 10/100, Single Port No Leds SMT Modular Jack

China RJMG168007101GR Rjmag 10/100, Single Port No Leds SMT Modular Jack supplier

Large Image :  RJMG168007101GR Rjmag 10/100, Single Port No Leds SMT Modular Jack

Product Details:

Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: ISO9001,SGS,UL,CE,REACH163
Model Number: RJMG168007101GR

Payment & Shipping Terms:

Minimum Order Quantity: 200 PCS
Price: Supportive
Packaging Details: Tray & Carton&Reel
Delivery Time: Stock or 4 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 3000000/Month
Contact Now
Detailed Product Description
Designe PN#: RJMG168007101GR Made In China: SM-LPJ10XXXXNL
Category: SMT Modular Jack Interface: 10/100Mbps
LED: Flexible Samples: Free Available

RJMG168007101GR Rjmag 10/100, Single Port No Leds SMT Modular Jack



RJMG168007101GR
Trader Part Number
RJMG168007101GR
Price Break
Unit Price
Extended Price
1-5
A
-
10-50
B
-
100-500
C-1
-
1,000-2,500
Supportive
Competitive
5,000
Dynamic
Dynamic
10,000
Dynamic
Dynamic
50,000
 Negotiable
Negotiable
100,000
 Negotiable
Negotiable
500,000
 Negotiable
Negotiable
Made in China
SM-LPJ10XXXXNL
Manufacturer
LINK-PP China
Description
Mag45-Rj45
Documents Available
PDF/3D/Step/IGS/Price/Cross
Quantity Available
200,000 PCS or 4 weeks



RJMG168007101GR ELECTRICAL SPECFICATIONS @
1.Turns Ratio(± 2%):
  TX=1CT:1CT      RX=1CT:1CT
2.OCL: 350uH Min
  @100KHz,100mV,8mA bias current
3.Insertion Loss:
  1-65MHz:-1.0dB Max
4.Return Loss(dB Min @100Ω± 15Ω):
  1-10MHz:-20      30MHz:-16
  60-80MHz:-12
5.Crosstalk(dB Min):
  1-10MHz:-40      30-60MHz:-35
  60-100MHz:-30
6.Common Mode Rejection(dB Min):
  1-50MHz:-30      50-130MHz:-20
7.Isolation Voltage: 1500Vrms Min
8.Operating Temperature: -40℃~+85℃

RJMG168007101GR Rjmag 10/100, Single Port No Leds SMT Modular Jack
