JD1-0001NL 1000 Base-T Rj45 Modular Jack Shielded Right Angle With LED

Large Image : JD1-0001NL 1000 Base-T Rj45 Modular Jack Shielded Right Angle With LED

Product Details:

Place of Origin:	China
Brand Name:	LINK-PP
Certification:	UL,ROHS,Reach,ISO
Model Number:	JD1-0001NL

Payment & Shipping Terms:

Minimum Order Quantity:	50/500/1000/25K
Price:	$0.05-$1.28
Packaging Details:	50pcs/tray,1200pcs/carton
Delivery Time:	Stock
Payment Terms:	TT,NET30/60/90 Days
Supply Ability:	4200K-PCS/Month

Contact Now

Detailed Product Description

Designe PN#:	JD1-0001NL	Alternate PN:	LPJG16370ADNL
Category:	Rj45 Tab-up Jack	Interface:	1000Mbps
LED:	Flexible Designed	Samples:	Available
Cross RF:	LPJG16370ADNL = JD1-0001NL
High Light:	rj-45 ethernet jack , industrial rj45 connector

JD1-0001NL 1000 Base-T Rj45 Modular Jack Shielded Right Angle With LED

JD1-0001NL = LPJG16370ADNL

Trader Part Number

JD1-0001NL

Price Break	Unit Price	Extended Price
1-5	A	-
10-50	B	-
100-500	C-1	-
1,000-2,500	Supportive	Competitive
5,000	Dynamic	Dynamic
10,000	Dynamic	Dynamic
50,000	Negotiable	Negotiable
100,000	Negotiable	Negotiable
500,000	Negotiable	Negotiable

Made in China

LPJG16370ADNL

Manufacturer

LINK-PP China

Description

Gigabyte Mag45 Connector

Documents Available

PDF/3D/Step/IGS/Price/Cross

Quantity Available

200,000 PCS or 4 weeks

JD1-0001NL ELECTRICAL SPECFICATIONS @
1.Turns Ratio(± 2%):
TX=1CT:1CT RX=1CT:1CT
2.OCL: 350uH Min
@100KHz,100mV,8mA bias current
3.Insertion Loss:
1-65MHz:-1.0dB Max
4.Return Loss(dB Min @100Ω± 15Ω):
1-10MHz:-20 30MHz:-16
60-80MHz:-12
5.Crosstalk(dB Min):
1-10MHz:-40 30-60MHz:-35
60-100MHz:-30
6.Common Mode Rejection(dB Min):
1-50MHz:-30 50-130MHz:-20
7.Isolation Voltage: 1500Vrms Min
