Rj45 Modular Jack With Magnetics JD1-0002NL 100base-tx 1000base-t

Rj45 Modular Jack With Magnetics JD1-0002NL 100base-tx 1000base-t
Rj45 Modular Jack With Magnetics JD1-0002NL 100base-tx 1000base-t
video play

Large Image :  Rj45 Modular Jack With Magnetics JD1-0002NL 100base-tx 1000base-t

Product Details:
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: JD1-0002NL
Payment & Shipping Terms:
Minimum Order Quantity: 50/500/1000/25K
Price: $0.09-$1.85
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 250000-320000/Month
Detailed Product Description
Designe PN#: JD1-0002NL Made In China: LPJG16391A4NL
Category: Rj45 Tab-up Connector Interface: 1000Mbps
LED: Flexible Designed Samples: Available
Highlight:

single port rj45

,

shielded rj45 plugs

Rj45 Modular Jack With Magnetics JD1-0002NL 100base-tx 1000base-t



Pulse Jack JD1-0002NL
Trader Part Number
JD1-0002NL
Price Break
Unit Price
Extended Price
1-5
A
-
10-50
B
-
100-500
C-1
-
1,000-2,500
Supportive
Competitive
5,000
Dynamic
Dynamic
10,000
Dynamic
Dynamic
50,000
 Negotiable
Negotiable
100,000
 Negotiable
Negotiable
500,000
 Negotiable
Negotiable
Made in China
LPJG16391A4NL
Manufacturer
LINK-PP China
Description
Gigabyte Mag45 Connector
Documents Available
PDF/3D/Step/IGS/Price/Cross
Quantity Available
200,000 PCS or 4 weeks



JD1-0002NL ELECTRICAL SPECFICATIONS @
1.Turns Ratio(± 2%):
  TX=1CT:1CT      RX=1CT:1CT
2.OCL: 350uH Min
  @100KHz,100mV,8mA bias current
3.Insertion Loss:
  1-65MHz:-1.0dB Max
4.Return Loss(dB Min @100Ω± 15Ω):
  1-10MHz:-20      30MHz:-16
  60-80MHz:-12
5.Crosstalk(dB Min):
  1-10MHz:-40      30-60MHz:-35
  60-100MHz:-30
6.Common Mode Rejection(dB Min):
  1-50MHz:-30      50-130MHz:-20
7.Isolation Voltage: 1500Vrms Min

Rj45 Modular Jack With Magnetics JD1-0002NL 100base-tx 1000base-t 0
