Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: RB1-105BAK1A
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4600K.PCS/Month
Specification: |
RB1-105BAK1A |
Cross Part: |
LPJG4803CNL |
Original Munafactuer: |
LINK-PP |
Lan: |
10/100/1000Mbps |
Termination: |
Solder |
Samples: |
Available Free |
Specification: |
RB1-105BAK1A |
Cross Part: |
LPJG4803CNL |
Original Munafactuer: |
LINK-PP |
Lan: |
10/100/1000Mbps |
Termination: |
Solder |
Samples: |
Available Free |
|
|
| Electrical Specifications @ 25℃ 1.Turns Ratio: TX=1:1 RX=1:1 2.INDUCTANCE(@100KHz,100mV,8mA DC BIAS): J1-J2;J3-J6;J4-J5;J7-J8: 350uH min 3.Insertion Loss: 1～100MHz:-1.0dB Max 4.Return Loss(dB Min.load 100Ω): 1～30MHz:-18 30～60MHz:-16 60～80MHz:-12 80～100MHz:-10 5.Crosstalk: 1～100MHz:-30dB Min 6.Common Mode Rejection: 1～100MHz:-30dB Min 7.Isolation Voltage:1500Vrms 8.Operating Temperature Range: -40℃～+85℃. |
|
