Product Details
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: RTA-3D4A1D1F
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: Supportive&Discount
Packaging Details: 60 pcs /Tray16trays/carton,Size37*30*30 cm, 11KGS (960 pcs) /Carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3000000/Month
Specification: |
RTA-3D4A1D1F |
Cross Part: |
LPJ2011KHNL |
Munafactuer: |
LINK-PP |
Lan: |
10/100 Mbps |
Termination: |
Solder |
Samples: |
Available Free |
Specification: |
RTA-3D4A1D1F |
Cross Part: |
LPJ2011KHNL |
Munafactuer: |
LINK-PP |
Lan: |
10/100 Mbps |
Termination: |
Solder |
Samples: |
Available Free |
|
|
| 1.Turns Ratio(±2%): TX=1CT:1CT RX=1CT:1CT 2.Inductance: 350uH MIN @100KHz,0.1V,8mA 3.Insertion Loss: 1-65MHz:-1.0dB MAX 4.Return Loss(dB MIN @100Ω±15Ω): 1-10MHz:-20 10-30MHz:-16 30-60MHz:-12 60-100MHz:-10 5.Crosstalk(dB MIN): 1-30MHz:-40 30-60MHz:-35 60-100MHz:-30 6.Common Mode Rejection: 1-50MHz:-30 50-150MHz:-20 7.Hi-Pot: 1500Vrms @60Hz 1 MIN 8.Operating Temperature Range: 0℃～+70℃. |
|
