RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)
RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)
RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)
RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)
RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)
RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)
RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)

RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)

Product Details

Place of Origin: Guangdong,China

Brand Name: LINK-PP

Certification: UL,ROHS,Reach,ISO

Model Number: RD1-215BAM1A

Payment & Shipping Terms

Minimum Order Quantity: 50/500/1000/25K

Price: $0.09-$1.85

Packaging Details: 50pcs/tray,1200pcs/carton

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 250000-320000/Month

Get Best Price

Product Details

Product Description
Highlight:

single port rj45

,

rj45 smd connector

Specification:
RD1-215BAM1A
Cross Part:
LPJG0801GENL
Munafactuer:
LINK-PP
Ethernet:
10/100/1000Base-T
Turns Ratio:
1:1
Samples:
Available Free
Specification:
RD1-215BAM1A
Cross Part:
LPJG0801GENL
Munafactuer:
LINK-PP
Ethernet:
10/100/1000Base-T
Turns Ratio:
1:1
Samples:
Available Free
RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)

RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000)

  • 10/100/1000 Full Duplex
  • 1X rj45, INT. MAG., LED, REVERSE LATCH
  • RD1-215BAM1A Gigabit Port
  • LPJG0801GENL Cross RD1-215BAM1A
  • LED optional, EMI-finger Optional.

1.Turns Ratio(±2%):


TX=1CT:1CT

RX=1CT:1CT
2.OCL: 350uH Min
@100KHz/0.1V With 8mA DC Bias
3.Return Loss(dB MIN):
1-30MHz:-18 30-60MHz:-16
60-80MHz:-12 80-100MHz:-10
4.Crosstalk(dB MIN):
1-30MHz:-40 30-60MHz:-35
60-100MHz:-30
5.Insertion Loss:
1-100MHz:-1.0dB MAX
6.CMR(dB MIN):
1-50MHz:-40 50-150MHz:-30
7.Hipot: 1500Vrms
8.Operating Temperature: 0℃～+70℃.

 RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000) 0
RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000) 1 RD1-215BAM1A RJ45 Single Port 1x Gigabit Ethernet (10/100/1000) 2
