Product Details
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: LPJD4011BENL
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: Supportive&Discount
Packaging Details: 60pcs /Tray,22 trays/carton,Size37*30*30 cm, 10KGS (1320 pcs) /Carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3000000/Month
Items: |
RJ45 Vertical Connector |
Part No: |
LPJD4011BENL (74990101210) |
Fast Ethernet Speed: |
10/100 Mbps |
Turn Ratio: |
1CT:1CT |
Top Entry Mounting: |
Straight 180 Degree |
LED Color (left-right): |
Green-yellow |
Items: |
RJ45 Vertical Connector |
Part No: |
LPJD4011BENL (74990101210) |
Fast Ethernet Speed: |
10/100 Mbps |
Turn Ratio: |
1CT:1CT |
Top Entry Mounting: |
Straight 180 Degree |
LED Color (left-right): |
Green-yellow |
The 74990101210 is an RJ45 LAN Connector with Integrated Transformer common mode choke. Compliant with IEEE 802.3u for 10/100Base-TX-Applications. Suitable for embedded PCs, hubs, routers, switches, and LAN applications.
Products Category | Vertical RJ45 Connector with Magnetics |
---|---|
LINK-PP Part Number | LPJD4011BENL |
Würth Elektronik Part Number | 74990101210 |
Applications |
10/100 Base-T, AutoMDIX |
LED Option | Green/Yellow |
Gender |
RJ45 Female Jack |
POE | NON POE |
Tab Direction | User Selectable or Tab UP |
EntryType | Top Entry 180° Angle |
Port Configuration | 1x1 |
Mounting Type | Through Hole |
Mounting Angle | Vertical Ethernet Connector |
Termination Style |
Solder |
Shield EMI Tabs | Without |
No of Contacts |
8 Contacts |
No of Positions | 8 Positions |
Housing Material | Thermoplastic PBT+30%G.F |
Flammability Rating | UL 94 V-0 |
Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
Minimum Operating Temperature | - 40 C |
Maximum Operating Temperature | + 85 C |
Features | Board Guide |
Lead-Free | Lead-Free |
PCB Retaining Post |
T POST |
Turns Ratio RX | 1CT:1CT |
Turns Ratio TX | 1CT:1CT |
Product Status | Active |
Packaging | Tray |
LINK-PP has rich experience in Magnetic RJ45 Connector manufacturing. Our commitment to quality and performance is unwavering. Our products meet the diverse needs of the networking and telecommunications industries. Either stacked RJ45 jacks or RJ45 connectors with integrated magnetics.
LINK-PP's manufacturing processes follow strict industry standards. The Magjack is used in networking equipment, communications equipment and industrial automation. Our continued collaboration with TI demonstrates our ability to deliver cutting-edge solutions. LINK-PP is the leading manufacturer of reliable RJ45 magnetic jacks. We offer competitive prices and efficient delivery.
1. It is not recommended to store LINKPP’s Low Profile RJ45 Jack for more than 12 months. Under other influences, the terminals may degrade, resulting in poor solderability.
2. Do not expose the module to direct sunlight.
3. Storage conditions in original packaging comply with DIN EN 61760-2.
4. The storage conditions apply to the storage time of the components, not to the shipping time.
