Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: P65-P0Z-18K7
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4600K.PCS/Month
Specification: |
P65-P0Z-18K7 |
Part No: |
LPJ0011CNL |
TAB Direction: |
Down |
Turn Ratio: |
1:1 |
Indicator: |
LED Flexible |
Samples: |
Available |
Specification: |
P65-P0Z-18K7 |
Part No: |
LPJ0011CNL |
TAB Direction: |
Down |
Turn Ratio: |
1:1 |
Indicator: |
LED Flexible |
Samples: |
Available |
ELECTRICAL SPECFICATIONS: @25℃
1.Turn Ratio(±2%):
TX=1CT:1 RX=1CT:1
2.Inductance OCL:
350uH MIN @ 100KHz 0.1V 8mA DC Bias
3.Insertion Loss:
-1.0dB MAX @ 1.0-100MHz
4.Return Loss:
-18dB MIN @ 1-30MHz
-15dB MIN @ 30-60MHz
-12dB MIN @ 60-80MHz
-10dB MIN @ 80-100MHz
5.Cross talk:
-40dB MIN @ 30MHz
-35dB MIN @ 60MHz
-30dB MIN @ 100MHz
6.Common Mode Rejection:
-40dB MIN @ 30MHz
-35dB MIN @ 60MHz
-30dB MIN @ 100MHz
7.Hipot: 1500Vrms
8.Operating Temperature Range:0℃ TO 70℃
|
|
