Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: RJ-049TC1
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.09-$1.85
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 250000-320000/Month
Specification: |
RJ-049TC1 |
Part No: |
LPJ4011CNL |
Ethernet: |
1x10/100Mbps |
Samples: |
Available |
Specification: |
RJ-049TC1 |
Part No: |
LPJ4011CNL |
Ethernet: |
1x10/100Mbps |
Samples: |
Available |
Features
◎ RoHS Compliant
◎ Fully shielded magnetics protect data from internally generated digital noise
◎ Reduces the overall length of the signal path for improved common mode performance
◎ Implements full common mode termination scheme with used and unused twisted pairs
◎ Meets IEEE802.3 Baseline Wander Compensation specification
◎ Integrates high voltage capacitor to chassis ground
◎ Supports all major transceivers with matched turns ration and complete integration of specified
termination
◎ Design for 100base-tx transmission over UTP-5 cable
◎ Operating TEMP. range:-40 ℃ to +85 ℃
◎ Storage TEMP. range:-55 ℃ to +125 ℃
◎ Primary OCL inductance: 350µH MIN. at 100KHz/0.1Vrms 8mA DC bias
|
|
