Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: HR911102A
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4600K.PCS/Month
Specification: |
HR911102A |
Part No: |
LPJ4025FBNL |
Ethernet: |
1x10/100Mbit |
Indicator: |
G-Y LEDs |
Mounting: |
R/A Shield |
Samples: |
Available Free |
Specification: |
HR911102A |
Part No: |
LPJ4025FBNL |
Ethernet: |
1x10/100Mbit |
Indicator: |
G-Y LEDs |
Mounting: |
R/A Shield |
Samples: |
Available Free |
Electrical Specifications @25℃
1.Turns Ratio:
TX=1CT:1 RX=1CT:1CT
2.Inductance: 350uH MIN
@100KHz,100mVrms,8 mA DC bias
3.Insertion Loss:
1～65MHz:-1.0dB MAX
4.Return Loss(dB MIN):
1～30MHz:-18 40MHz:-16
50MHz:-12 60MHz:-10
5.Crosstalk(dB MIN):
30MHz:-40 60MHz:-35
100MHz:-30
6.CMR:(dB MIN):
30MHz:-30 60MHz:-20
100MHz:-20
7.Hipot: 1500Vrms
8.Operating Temperature: -40℃～+85℃.
|
|
