Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: DEM-432XT
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Specifications: |
DEM-432XT |
Form Factor Type: |
SFP+ |
Fiber Media Support: |
Single-Mode |
Distance Capacity: |
10 Km |
DDM: |
Yes |
Speed: |
10 Gbps |
Connector: |
Duplex LC |
Directional: |
Single Direction |
Wavelength: |
1310nm |
Sensitivity: |
-12.6 DBm |
Power: |
3.3 V |
Dimensions(W X D X H): |
14.8 X 56.5 X 11.85 Mm |
Specifications: |
DEM-432XT |
Form Factor Type: |
SFP+ |
Fiber Media Support: |
Single-Mode |
Distance Capacity: |
10 Km |
DDM: |
Yes |
Speed: |
10 Gbps |
Connector: |
Duplex LC |
Directional: |
Single Direction |
Wavelength: |
1310nm |
Sensitivity: |
-12.6 DBm |
Power: |
3.3 V |
Dimensions(W X D X H): |
14.8 X 56.5 X 11.85 Mm |
Feature Highlights
Standard Compliance : IEEE-802.3ae 10GBASE-LR
Form Factor Type - SFP+
Fibre Channel FC-PI Standard- 1200-SM-LL-L
Fiber Media Support -Single-Mode
Distance Capacity - 10 km
FEATURES
Hot Pluggable Yes
MSA Compliant Yes
RoHS Compliant Yes
MAC Address Update Yes
DDM (Digital Diagnostics Monitoring) Yes
Speed 10 Gbps
INTERFACE
Connector Duplex LC Connector
Single/Bi-Directional Single Direction
Wavelength 1310nm
Output Optical Power (TX Optical Power)
Max.: 0.5 dBm
Min.: -8.2 dBm
Input Optical Power (RX Optical Power)
Max.: 0.5 dBm
Min.: -12.6 dBm
Sensitivity -12.6 dBm
Cable Type Single-mode 9/125 μm fiber
OPERATING Power 3.3 V
Maximum Input Current 285 mA
Minimum Power Budget 4.4 dB
Maximum Power Budget 17.6 dB
Heat Generated 3.4 kJ/h
RELIABILITY
MTBF (Hours) 3,390,000
PHYSICAL & ENVIRONMENTAL Operating Temperature -5 to 70 °C
Storage Temperature -40 to 85 °C
Operating Humidity 0 to 85%
Storage Humidity 0 to 85%
Weight 0.05 lbs (22g)
Dimensions(W x D x H) 0.58 x 2.22 x 0.47 inches (14.8 x 56.5 x 11.85 mm) Compliant with SFF8432
Bail Latch Color Blue
Certifications FCC Class A, CE Class A, ICES-003, VCCI Class A, C-Tick, BSMI
EMISSION (EMI) AND SAFETY EMI CE, FCC, VCCI
Safety CSA, TUV, CDRH
