Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: RT7-114A8V1F
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4600K.PCS/Month
Specifications: |
RT7-114A8V1F |
P/N: |
LPJ16270AENL |
Hi-pot: |
1500V |
LED Color: |
Flexible |
Mechanical: |
21.25x15.90x13.40mm |
Samples: |
Free |
Specifications: |
RT7-114A8V1F |
P/N: |
LPJ16270AENL |
Hi-pot: |
1500V |
LED Color: |
Flexible |
Mechanical: |
21.25x15.90x13.40mm |
Samples: |
Free |
| 1.Designed to support application,such as SOHO(ADSL |
| modems),LAN-on-Motherboard(LOM),hub and Switches. |
| 2.Meets IEEE 802.3 specification |
| 3.Connector Materials: |
| Housing: Thermoplastic PBT+30%G.F UL94V-0 |
| Contact: Phosphor Bonze C5210R-EH Thickness=0.35mm |
| Pins: Brass C2680R-H Thickness=0.35mm |
| Shield: SUS 201-1/2H Thickness=0.2mm |
| Contact plating: Gold 6 micro-inches min.In contact area. |
| 4.Wave solder tip temperature: 265℃ Max, 5 Sec Max |
| 5.UL Certification: File Number E484635 |
