Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: 7499011125
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: Supportive
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4600K.PCS/Month
Specification: |
7499011125 |
Specifications: |
MIC24011-5108T-LF3 |
P/N: |
LPJ4012GDNL |
Mounting: |
THT |
Termination: |
Solder |
Samples: |
Free |
Specification: |
7499011125 |
Specifications: |
MIC24011-5108T-LF3 |
P/N: |
LPJ4012GDNL |
Mounting: |
THT |
Termination: |
Solder |
Samples: |
Free |
1.Designed to support application,such as SOHO(ADSL
modems),LAN-on-Motherboard(LOM),hub and Switches.
2.Meets IEEE 802.3u specification
3.Connector Materials:
Housing: Thermoplastic PBT+30%G.F UL94V-0
Contact: Phosphor Bonze C5210R-EH Thickness=0.35mm
Pins: Brass C2680R-H Thickness=0.35mm
Shield: SUS 201-1/2H Thickness=0.2mm
Contact plating: Gold 6 micro-inches min.In contact area.
4.Wave solder tip temperature: 265℃ Max, 5 Sec Max
5.UL Certification: File Number E484635
LINK-PP Can also offer 100% Compatible Equivalent Part to the follow parts below:
| MIC24120-5101-LF3 | 7498011002 |
| MIC24121-5308-LF3 | 7498011122 |
| MIC24121-5408-LF3 | 7498011125 |
| MIC26023-5134-LF3 | 7498011211 |
| MIC38121-5356-LF3 | 7498111120 |
| MIC26010-5101-LF3 | 7499010005 |
| MIC24311-0101-LF3 | 7499010121 |
| MIC24611-5104-LF3 | 7499010122 |
| MIC24611-0101-LF3 | 7499010124 |
| MIC24611-5117-LF3 | 7499010126 |
| MIC25213-5210-LF3 | 7499010213 |
| MIC24010-5101-LF3 | 7499011002 |
| MIC24011-0101-LF3 | 7499011121 |
| MIC24011-5108-LF3 | 7499011125 |
| MIC25113-0141-LF3 | 7499011211 |
| MIC24013-0102-LF3 | 7499011215 |
| MIC24112-0101-LF3 | 7499011225 |
| MIC2411C-6131-LF3 | 7499011610 |
| MIC24F11-0101-LF3 | 7499012121 |
| MIC24811-0104-LF3 | 7499021121 |
| MIC24712-0108-LF3 | 7499031221 |
| MIC38611-5166-LF3 | 7499110120 |
| MIC3811A-0255-LF3 | 7499111241 |
| MIC3811B-0158-LF3 | 7499111422 |
| MIC3801J-5169-LF3 | 7499111990 |
| MIC66211-5171-LF3 | 7499210121 |
| MIC66210-5171-LF3 | 7499210122 |
| MIC66611-5171-LF3 | 7499210123 |
| MIC66311-0171-LF3 | 7499210124 |
| MIC64013-5180-LF3 | 7499210211 |
| MIC66011-5171-LF3 | 7499211121 |
