634008149821 / LPJES101XDNL 8pin SMT Rj45 latch-up without LEDs

China 634008149821 / LPJES101XDNL 8pin SMT Rj45 latch-up without LEDs supplier
634008149821 / LPJES101XDNL 8pin SMT Rj45 latch-up without LEDs supplier 634008149821 / LPJES101XDNL 8pin SMT Rj45 latch-up without LEDs supplier

Large Image :  634008149821 / LPJES101XDNL 8pin SMT Rj45 latch-up without LEDs

Product Details:

Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: ISO9001,SGS,UL,CE,REACH,RoHS
Model Number: 634008149821

Payment & Shipping Terms:

Minimum Order Quantity: 1000
Price: Supportive
Packaging Details: Tray&Carton
Delivery Time: Stock or 4 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 3000000/Month
Contact Now
Detailed Product Description
Specifications: 634008149821 Equivalent: LPJES101XDNL
Mounting: SMD Application: Cat5
Termination: Solder LEDs: None Or Optional

634008149821 | LPJES101XDNL 8pin SMT Rj45 latch-up without LEDs



634008149821 Equivalent / Cross pin to pin compatible part.

8pin SMT Rj45 # LPJES101XDNL  Surface Mounting connector to Ethernet

634008149821 / LPJES101XDNL 8pin SMT Rj45 latch-up without LEDs

NOTES:


Electrical:
 1.Voltage rating            : 125 VAC RMS
 2.Current Rating            : 1.5 AMP
 3.Contact resistance        : 20 mΩ Max
 4.Insulation resistance     : 1000 MΩ Min @500V DC
 5.Dielectric strength       : 1000 VAC RMS 50Hz,1MIN.
MECHANICAL:
 1.Housing & Insert Material : PBT UL94V-0.
 2.Contact Material          : Phospor bronze T=0.30mm
 3.Plating                   :Gold Plating OVER nickel,
                              Gold plated on content area 3U"
 4.Operating Life            : 750 Cycles Min.
ENVIRONMENTAL:
 1.Storage                   : -40℃ ~ +85℃
 2.Operation                 : -40℃ ~ +85℃.
 3.Wave solder temperature   : 265℃ 5 Sec MAX



Gold Plating:

1.5U;3U;6U;16U



LINK-PP Specifications:



LPJES1010DNL

LPJES1011DNL

LPJES1012DNL

LPJES1013DNL

LPJES1014DNL

LPJES1015DNL
