LP44805NL10/100 BASE –T Quad Port Transformer VP6017 LF With 720mA DC Capability

China LP44805NL10/100 BASE –T Quad Port Transformer VP6017 LF With 720mA DC Capability supplier
LP44805NL10/100 BASE –T Quad Port Transformer VP6017 LF With 720mA DC Capability supplier LP44805NL10/100 BASE –T Quad Port Transformer VP6017 LF With 720mA DC Capability supplier LP44805NL10/100 BASE –T Quad Port Transformer VP6017 LF With 720mA DC Capability supplier

Large Image :  LP44805NL10/100 BASE –T Quad Port Transformer VP6017 LF With 720mA DC Capability

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO,UL,SGS,Reach,RoHS
Model Number: VP6017 LF

Payment & Shipping Terms:

Minimum Order Quantity: 500/1000
Price: Supportive
Packaging Details: Reel Package
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 3800000PCS/Month
Contact Now
Detailed Product Description
Specification: VP6017 LF Update PN: LP44805NL
Turns Ratio: 1CT:1CT Mounting: Surface Mount
Ethernet: 4x10/100 Mbps Power Isolation Voltage: 1500Vrms
Capability: 720mA DC Archivi Disponibil: PDF/3D/ISG/Stp/Step/Datasheet

VP6017 LF | LP44805NL10/100 BASE –T QUAD PORT VOICE OVER IP MAGNETICS MODULE
  1. IEEE 802.3at/ANSI X3.263 compliant performance.
  2. Suitable for End-span POE applications with 720mA current capability.
  3. Comply with RoHS & Halogen Free requirements.
  4. Operating temperature range: 0℃ to +70℃.
  5. Storage temperature range: -25℃ to +125℃.
  6. LP44805NL Quad Port 10/100Base-Tx POE+ Magnetics Module
  7. Equivalent Cross to VP6017 LF Specifications
  8. 48 pins 4x10/100Mbps POE+ Transformer

Electrical Specification @25℃
1.Insertion Loss(dB Max):
0.1MHz: -1.2
1-125MHz: -2.0
2.Return Loss(dB Min):
1-40MHz: -16
40-100MHz: -10
3.Crosstalk(dB Min):
30MHz: -43
60MHz: -37
100MHz: -33
4.CMRR(dB Min):
30MHz: -30
200MHz: -15
5.DCR Balance: 1 Ω ±0.05Ω
6.OCL:
(1) 350uH Min @20mA DC Bias
(2) 120uH Min @30mA DC Bias
7.Temperature rise of 35℃ when supplying
720mA DC continuous over 8 pairs
8.Hipot:1500Vrms
9.Operating Temperature: 0℃~70℃.
