Surface Mount 10/100 Transformer 4800Vrms ,749014012 Power Over Ethernet Transformer 350µH

China Surface Mount 10/100 Transformer 4800Vrms ,749014012 Power Over Ethernet Transformer 350µH supplier
Surface Mount 10/100 Transformer 4800Vrms ,749014012 Power Over Ethernet Transformer 350µH supplier Surface Mount 10/100 Transformer 4800Vrms ,749014012 Power Over Ethernet Transformer 350µH supplier

Large Image :  Surface Mount 10/100 Transformer 4800Vrms ,749014012 Power Over Ethernet Transformer 350µH

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO,UL,Reach,SGS,RoHS
Model Number: 749014012

Payment & Shipping Terms:

Minimum Order Quantity: 2000
Price: Supportive
Packaging Details: Reel Package
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 3000K/month
Contact Now
Detailed Product Description
Specifications: 749014012 Equivalent: LPXXXXNL
Turn Ratio: 1:1 Mounting: SMD
Ethernet: 1x10/100Base-Tx Dielectric: 4800Vrms
Archivi Disponibili: PDF/3D/ISG/Stp/Step/Datasheet

Surface Mount 10/100 Transformer 4800Vrms ,749014012 Power Over Ethernet Transformer 350µH
  • Ethernet TRANSFORMER FOR GENERAL PURPOSE APPLICATION(S)
  • l IEEE 802.3 Ethernet Compatible,10/100 Base-TX
  • Surface Mountable(Miniature size)
  • Coil Structure: Toroidal
  • 10/100 Base-T Transformer Modules
  • Compatible of 749014012 Equivalent Specifications
  • Equivalent to 749014012
  • operating temperature: 0°C - + 70°C
  • Hipot test: 4800Vrms 1min.
  • Compliant with IEEE 802.3u for 10/100Base-TX-Applications
  • Auto MDIX capable

 749014012 10/100 Transformer 1 port 350µH, 4800Vrms Dielectric

SPECIFICATIONS



Mfr Package Description ROHS COMPLIANT
REACH Compliant Yes
EU RoHS Compliant Yes
Status Active
Transformer Type LINK-PP made In China
Application GENERAL PURPOSE
Isolation Voltage 4800 Vrms
Manufacturer Series 749014012 Cross
Mounting Feature SURFACE MOUNT
Number of Functions 1
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Primary Inductance 350.0 µH
Turns Ratio (Np:Ns) 1:1
Height 10.85 mm
Length 24.55 mm
Width 18.25 mm
Additional Feature HEIGHT DIM INCLUDE TERMINALS ALSO



Surface Mount 10/100 Transformer 4800Vrms ,749014012 Power Over Ethernet Transformer 350µH
