Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: H1112NLT / H1126NLT
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Specifications: |
H1126NLT |
Inductance: |
350µH |
Turns Ratio: |
1 : 1 Or 1CT: 1.41CT |
Mounting Type: |
Surface Mount |
Dimension: |
14.81 Mm X 14.73 Mm X 4.88mm |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
Specifications: |
H1126NLT |
Inductance: |
350µH |
Turns Ratio: |
1 : 1 Or 1CT: 1.41CT |
Mounting Type: |
Surface Mount |
Dimension: |
14.81 Mm X 14.73 Mm X 4.88mm |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
| roduct Category: | Audio Transformers / Signal Transformers |
| Manufacturer: | Pulse |
| RoHS: | Details |
| Specifications | H1112 , H1126 |
| Termination Style: | SMD/SMT |
| Frequency Range: | 100 kHz to 100 MHz |
| Isolation Voltage: | 1.5 kV |
| Minimum Operating Temperature: | 0 C |
| Maximum Operating Temperature: | + 70 C |
| Number of Channels: | Single |
| Product: | LAN |
| Type: | Module |
| Application: | 100Base-TX |
| Length: | 14.81 mm |
| Width: | 14.73 mm |
| Height: | 4.88 mm |
| Packaging: | Tube |
| Brand: | Pulse |
| Product Type: | Transformers |
| Shielding: | Unshielded |
Audio Transformers / Signal Transformers 100BaseTX SMD NonPoE 1-Port
