L12N001-0 DIP 1000 BASE –T Single Port Lan Magnetic Transformer

China L12N001-0 DIP 1000 BASE –T Single Port Lan Magnetic Transformer supplier
L12N001-0 DIP 1000 BASE –T Single Port Lan Magnetic Transformer supplier L12N001-0 DIP 1000 BASE –T Single Port Lan Magnetic Transformer supplier

Large Image :  L12N001-0 DIP 1000 BASE –T Single Port Lan Magnetic Transformer

Product Details:

Place of Origin: China
Brand Name: LINK-PP
Certification: SGS, UL,CE,ISO9001:2008
Model Number: L12N001-0

Payment & Shipping Terms:

Minimum Order Quantity: 500/1000
Price: supportive
Packaging Details: tape & reel / tube
Delivery Time: stock or 4-5 weeks
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000kpcs/month
Contact Now
Detailed Product Description
P/N: L12N001-0 X'fmr: 1000 Base-T Single Port
Mounting: DIP Application: EPON/ GPON/ IP Camera
Files: PDF / Datasheet / 3D / IGS / Step /Stp Compatible: L12N001-0=>LPxxxNL
Samples: Available 3 PCS Turn Radio: 1:1

L12N001-0 DIP 1000 BASE –T Single Port Lan Magnetic Transformer



L12N001-0
Series: Transformer REACH Compliant: Yes
P/N: L12N001-0 EU RoHS Compliant: Yes
Manufacturer: LINK-PP China RoHS Compliant: Yes
Speed: 1000 Base-T PORT: 1
Package: DIP Turns Ratio (Np:Ns) 1:1; 1:1
PIN: 12 Status: Active



NOTES:

1.Designed to support application,such as SOHO(ADSL modems),LAN-on-Motherboard(LOM),

   hub and Switches.

2.Meets IEEE 802.3 specification

3.Connector Materials:

   Housing: Thermoplastic PBT+30%G.F UL94V-0

   Contact: Phosphor Bonze C5210R-EH Thickness=0.35mm

   Pins: Brass C2680R-H Thickness=0.35mm

   Shield: SUS 201-1/2H Thickness=0.2mm

   Contact plating: Gold 6 micro-inches min.In contact area.

4.Wave solder tip temperature: 265℃ Max, 5 Sec Max

5.UL Certification: File Number E484635



Application;

1 VME, VPX, and VXI Switches

2 Video Cables

3 Ink and Toner Cartridges

4 Microcontrollers (MCU)



L12N001-0 DIP 1000 BASE –T Single Port Lan Magnetic Transformer



Tag: Gigabit Ethernet Transformer,1000Base-T LAN Filter
