Product Details:
Payment & Shipping Terms:
|
| Specifications: | FTLF8519F2xCL | Data Rate: | 2.5Gbps |
|---|---|---|---|
| Distance: | 300m | LINK-PP PN: | LFF-8524-02IDS |
| Fiber Type: | Singlemode Glass | Emitter: | FP Laser |
| Applications: | Ethernet | Connector: | LC Duplex |
| Mounting: | Pluggable,SFP | Environment: | Lead Free / RoHS Compliant |
| High Light: | FTLF8519F2xCL,fiber optic transceiver,sfp optical module |
||
| Specifications: | FTLF8519F2xCL |
| LINK-PP Part Number: | LFF-8524-02IDS |
| Product Class: | Fiber Optics |
| Product Family: | Optical Transceivers |
| Product Series: | SFP |
| Product Name: | SFP Optical Transceivers |
| Status Available: | Active |
| RoHS: | RoHS-6 Compliance |
|
Specifications:
|
|
|
Data Rate: |
2.5Gbps |
| Wavelength: | 1300nm |
| Maximun Distance: | 10000m |
| Fiber Type: | Singlemode Glass |
| Emitter: | FP Laser |
| Voltage-Supply: | 3.14V~3.47V |
| Applications: | Ethernet |
| Connector Type: | LC Duplex |
| Mounting Type: | Pluggable,SFP |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Moisture Sensitivity Level(MSL): | 3 (168 Hours) |
|
Feature Description:
|
Small Form Factor 2X5 pin Package
Duplex LC Single-Mode Transceiver
Operating data rate up to 2.5Gbps
850nm VESCL Transmitter, 300m with 50/125µm or 62.5/125um MMF
1310nm FP Laser Transmitter, 2km with 50/125µm or 62.5/125um MMF
1310nm DFB Laser Transmitter
15km with 9/125µm SMF
40km with 9/125µm SMF
1550nm DFB Laser Transmitter,
40km with 9/125µm SMF
80km with 9/125µm SMF
Single 3. 3V Power supply
DC/AC Coupled Signal Input / Output
LVTTL Transmitter Disable Input
LVTTL Signal Detect Output
Operating Case Temperature
Standard: 0°C ~+70°C
Industrial:-40°C ~+85°C
Fiber Channel Links
2x Fiber Channel Links
Other Optical Link
