Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: TX1089NL
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Specifications: |
TX1089NL |
Cross Rf: |
TX1089NL => LPB81089NLE |
Number Of Ports: |
Dual Port |
Mounting: |
SMD |
Ethernet: |
1x10/100Base-Tx |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
Specifications: |
TX1089NL |
Cross Rf: |
TX1089NL => LPB81089NLE |
Number Of Ports: |
Dual Port |
Mounting: |
SMD |
Ethernet: |
1x10/100Base-Tx |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
|
| Specifications | TX1089NL |
| REACH Compliant | Yes |
| EU RoHS Compliant | Yes |
| Cross Compatible | LPB81089NLE |
| Transformer Type | DATACOM TRANSFORMER |
| Application | GENERAL PURPOSE |
| Approvals | UL |
| Insertion Loss | 1.0 dB |
| Isolation Voltage | 1500.0 V |
| Mounting Feature | SURFACE MOUNT |
| Operating Frequency-Min | 100.0 kHz |
| Operating Frequency-Max | 125000.0 kHz |
| Operating Temperature-Min | -40.0 Cel |
| Operating Temperature-Max | +85.0 Cel |
| Primary Inductance | 350 |
| Turns Ratio (Np:Ns) | 1:1; 1:1 |
| Height(mm) | 6.20 mm |
| Length(mm) | 12.70 mm |
| Width(mm) | 9.30 mm |
