Product Details
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: KRJ-5224GYWKNL
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.09-$1.85
Packaging Details: Tray & Carton&Reel
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3000000/Month
Design PN#: |
KRJ-5224GYWKNL |
Samples: |
Available Free |
LEDs: |
Green / Yellow |
Port: |
Single |
Made In China: |
LPJE681NENL |
File: |
PDF/3D/ISG/Stp/Step/Datasheet |
Design PN#: |
KRJ-5224GYWKNL |
Samples: |
Available Free |
LEDs: |
Green / Yellow |
Port: |
Single |
Made In China: |
LPJE681NENL |
File: |
PDF/3D/ISG/Stp/Step/Datasheet |
| Vertical RJ45 Connector in Networking without Integrated Magnetics,Green/Yellow LED,RoHS | |
| LINK-PP Part Number | LPJE681NENL |
| Other Part Number | KRJ-5224GYWKNL |
| Application-Lan | ETHERNET(NoN PoE) |
| AutomDX | YES |
| Bst Circuit | YES |
| Configuration RX | T,C |
| Configuration TX | T,C |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u" |
| Cores per Port | - |
| Diodes | NO DIODES |
| LED Option | Green/Yellow LEDs |
| Latch | TAB UP |
| Number of Ports | 1X1 |
| PCB | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Retaining Post | T POST |
| Package Height (Inches) | 0.634 |
| Package Height (mm) | 16.10 |
| Package Length (Inches) | 0.632 |
| Package Length (mm) | 16.05 |
| Package Width (Inches) | 0.604 |
| Package Width (mm) | 15.35 |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Search | YES |
| Shield EMI Tabs | WITHOUT |
| Speed | RJ45 without Magnetics |
| Temperature | -40 TO + 85℃ |
| Turns Ratio RX | 1CT:1CT |
| Turns Ratio TX | 1CT:1CT |
