LP5020NL 1000Base-T Dual Ethernet Magnetic Transformers B78476A8250A003

China LP5020NL 1000Base-T Dual Ethernet Magnetic Transformers B78476A8250A003 supplier
LP5020NL 1000Base-T Dual Ethernet Magnetic Transformers B78476A8250A003 supplier LP5020NL 1000Base-T Dual Ethernet Magnetic Transformers B78476A8250A003 supplier

Large Image :  LP5020NL 1000Base-T Dual Ethernet Magnetic Transformers B78476A8250A003

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO,UL,Reach,SGS,RoHS
Model Number: B78476A8250A003

Payment & Shipping Terms:

Minimum Order Quantity: 500pcs
Price: Supportive
Packaging Details: Reel Package
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 3000K/month
Contact Now
Detailed Product Description
Specifications: B78476A8250A003 P/N: LP5020NL
Ethernet: 2x Gigabit Dimension: 27.94x10.92x8.66mm
Mounting: SMD Samples: Free
Archivi Disponibili: PDF/3D/ISG/Stp/Step/Datasheet

LP5020NL 1000Base-T Dual Magnetic Modules Gigabit Transformers B78476A8250A003





  1. LP5020NL 1000Base-T Dual Magnetic
  2. CoilStructure:Toroidal
  3. SMT,50Pins4.gigabit ethernet transformer
  4. Dual 1000Base-T Transformer LP5020NL



Dual Port, 1000 BASE-T Ethernet Telecom Transformer Modules, SMD,Rohs
LINK-PP Part Number LP5020NL
Speed 1000BASE-T
Number of Ports Dual
Application - LAN ETHERNET (NON PoE)
Package SMD
Temperature - 40 TO + 85
AutomDX YES
Comment SAME AS NL VERSION
Configuration RX T,C,S
Configuration TX T,C,S
Construction OPEN FRAME
Cores Per Port 16
Package Height (Inches) 0.340
Package Height (mm) 8.66
Package Length (Inches) 1.100
Package Length (mm) 27.94
Package Width (Inches) 0.430
Package Width (mm) 10.92
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT



LP5020NL 1000Base-T Dual Ethernet Magnetic Transformers B78476A8250A003 0



LP5020NL 1000Base-T Dual Ethernet Magnetic Transformers B78476A8250A003 1



Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem





FAQ



Q1: Can provide a sample test?

A: Yes,we are pleased to supply samples to test and check quality. free samples is also acceptable.

Q2: How about the MOQ?

A: NO MOQ , 1pcs OK . Small order welocome.

Q3: What’s the lead time?

A: Sample :1-3 days.Mass batch: 5-15 days .depend on the specific delivery time depends on the items and the quantity of your order. Please contact us for details.

Q4: Can make customized products ?

A: Yes, we can develop new mold at you need if you can provide us with the samples or drawings and specification.

Q5: What kind of payment do accept ?

A: ONLINE ( TRADE INSURANCE),,VISA,T/T,Western union,MoneyGram.



LP5020NL 1000Base-T Dual Magnetic Modules Gigabit Transformers B78476A8250A003
