Home > products > Discrete Magnetic Transformers > 760390011 Lan Discrete Transformer Modules Audio And Signal Flyback POE LPB06024ANL

760390011 Lan Discrete Transformer Modules Audio And Signal Flyback POE LPB06024ANL

Product Details

Place of Origin: Guangdong,China

Brand Name: LINK-PP

Certification: UL,RoHS,Reach,ISO

Model Number: 760390011

Payment & Shipping Terms

Minimum Order Quantity: 400/2000/10K/25K

Price: $0.06-$3.2

Packaging Details: T&R

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 3KK/Month

Get Best Price
Highlight:

smt magnetic transformer

,

surface mounting transformer

Specifications:
760390011
Cross In China:
LPB06024ANL
Family:
FORWARD TRANSFORMER
Mounting Type:
SMD
Voltage - Auxillary:
10V @ 50mA
Samples:
Free Available
Specifications:
760390011
Cross In China:
LPB06024ANL
Family:
FORWARD TRANSFORMER
Mounting Type:
SMD
Voltage - Auxillary:
10V @ 50mA
Samples:
Free Available
760390011 Lan Discrete Transformer Modules Audio And Signal Flyback POE LPB06024ANL

760390011 Transformers Audio & Signal Flyback PoE LPB06024ANL





Packaging

Tape & Reel (TR)



Part Status

Active



Type

For DC/DC Converters



Applications

Forward, Push-Pull Converters



Intended Chipset

SN6501



Chipset Manufacturer

Texas Instruments



Voltage - Primary

-



Voltage - Auxiliary

-



Voltage - Isolation

1500Vrms



Inductance @ Frequency

1mH @ 10kHz



Frequency

10kHz



Operating Temperature

-40°C ~ 125°C



Mounting Type

Surface Mount



Size / Dimension

0.265" L x 0.281" W (6.73mm x 7.14mm)



Height - Seated (Max)

0.170" (4.32mm)



Footprint

0.265" L x 0.395" W (6.73mm x 10.05mm)


Competitive Price And Service
• Provide New Design For Customer Requirements
• Delivery Time:2-3 Weeks After Orders

Packing
1. Conventional packing: braid package/blister packaging/plastic pipe packaging/tape packaging.
2. We can do the packing according to the customer's requirement, but the price is different.


Shipping:
By Sea : If you have freight forwarder , they can handle shipping for you . If you don't have it , we can provide the cheapest shipping cost to you .
By Air : You can try to contact with DHL,Fedex,UPS express etc. after got weight and CBM from us . But it's more cheaper by China express agent , you can contact with our sales to get the cheapest freight cost


Product Lines
Now has 22 production lines, using IE technology to analyze the process statistics, continuously improve the production process and technology, improve production efficiency.

FAQ:
Q1: Are you a factory or trading company?
A1: We have 3 factories. Welcome to visit us!
Q2: May I buy samples from you?
A2: Yes! You are welcome to place sample order to test our superior quality and service
Q3: What is your Warranty?
A3: All the network cabling products will have 1 years Warranty.
Q4: What payment method do you accept?
A4: T/T(Bank transfer), Western Union, Money Gram, PayPal.

Q5: May I know the status of my order?
A5: Yes .The order information and photos at different production stage of your order will be sent to you and the information will be updated in time.
