350uh min HST-1201DR 10/100Base-T Through Hole Transformer

Product Details

Place of Origin: Guangdong,China

Brand Name: LINK-PP

Certification: UL,RoHS,Reach,ISO

Model Number: HST-1201DR

Payment & Shipping Terms

Minimum Order Quantity: 400/2000/10K/25K

Price: $0.06-$3.2

Packaging Details: T&R

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 3KK/Month

Get Best Price
Highlight:

100Base-T Through Hole Transformer

,

350uh Min Through Hole Transformer

,

HST-1201DR Transformer

LINK-PP P/N:
HST-1201DR
Familiy:
10/100 Magnetics
Mounting:
SMT
Samples:
Available
Number Of Ports:
Single
Hi-pot:
1500Vrms
OCL:
350uh Min
Archivi Disponibili:
PDF/3D/ISG/Stp/Step/Datasheet
LINK-PP P/N:
HST-1201DR
Familiy:
10/100 Magnetics
Mounting:
SMT
Samples:
Available
Number Of Ports:
Single
Hi-pot:
1500Vrms
OCL:
350uh Min
Archivi Disponibili:
PDF/3D/ISG/Stp/Step/Datasheet
350uh min HST-1201DR 10/100Base-T Through Hole Transformer

HST-1201DR 10/100 Base-T Single port through hole Magnetics

Detailed Information:



Single Port, 10/100 BASE-T Ethernet Transformer Modules, SMD,Rohs
Part Number HST-1201DR
Speed 10/100 BASE-T
Number of Ports

Single

Application - LAN ETHERNET (NON PoE)
Package SMD
AutomDX YES
Comment SAME AS NL VERSION
Configuration RX T,C,S
Configuration TX T,C,S
Construction OPEN FRAME
Cores Per Port 2
Package Height (Inches) -
Package Height (mm)

3.00

Package Length (Inches) -
Package Length (mm) 12.60
Package Width (Inches) -
Package Width (mm) 7.20
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT
