Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: HST-4047DR
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
LINK-PP P/N: |
HST-4047DR |
Familiy: |
10/100 Magnetics |
Mounting: |
DIP |
Samples: |
Available |
Number Of Ports: |
Single |
Hi-pot: |
1500Vrms |
OCL: |
350uh Min |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
LINK-PP P/N: |
HST-4047DR |
Familiy: |
10/100 Magnetics |
Mounting: |
DIP |
Samples: |
Available |
Number Of Ports: |
Single |
Hi-pot: |
1500Vrms |
OCL: |
350uh Min |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
● Symmetrical TX and RX channels for auto MDI/MDIX capability.
● Approved for use with Broadcom BCM5226/BCM5228 and Level One LXT9784.
● Primary inductance(Lp)350uH min.@ 100KHz,0.1Vrms,DC 8mA.
● LL:0.5uH Max @100KHz, 0.1V.
Detailed Information:
| Single Port, 10/100 BASE-T Ethernet Transformer Modules, SMD,Rohs | |
| Part Number | HST-4047DR |
| Speed | 10/100 BASE-T |
| Number of Ports |
Single |
| Application - LAN | ETHERNET (NON PoE) |
| Package | SMD |
| AutomDX | YES |
| Comment | SAME AS NL VERSION |
| Configuration RX | T,C,S |
| Configuration TX | T,C,S |
| Construction | OPEN FRAME |
| Cores Per Port | 16 |
| Package Height (Inches) | - |
| Package Height (mm) |
7.60 |
| Package Length (Inches) | - |
| Package Length (mm) | 37.80 |
| Package Width (Inches) | - |
| Package Width (mm) | 7.60 |
| Turns Ratio RX | 1CT:1CT |
| Turns Ratio TX | 1CT:1CT |
Product Lines
Now has 22 production lines, using IE technology to analyze the process statistics, continuously improve the production process and technology, improve production efficiency.
FAQ
1.Are you the real manufacturer?
Yes. We are the real manufacturer since 1997.
2.Can you accept small order?
Yes, small order is available .We support new project of our customers as we know business is always from
small order.
3.Which kind of certification you have ?
ISO9001, SGS, UL, RoHs.
4.What is your delivery time?
Usually within 2-3 working days
5.What is your payment way?
T/T, L/C, D/P,MoneyGram,Western Union and Paypal.
6.Can you supply customized products and logo?
-Yes. We supply OEM&ODM service. You can send us your drawing.
