HST-24056SXCR 0.1Vrms Gigabit Ethernet Transformer 100KHz
HST-24056SXCR 0.1Vrms Gigabit Ethernet Transformer 100KHz
HST-24056SXCR 0.1Vrms Gigabit Ethernet Transformer 100KHz

HST-24056SXCR 0.1Vrms Gigabit Ethernet Transformer 100KHz

Product Details

Place of Origin: Guangdong,China

Brand Name: LINK-PP

Certification: UL,RoHS,Reach,ISO

Model Number: HST-24056SXCR

Payment & Shipping Terms

Minimum Order Quantity: 400/2000/10K/25K

Price: $0.06-$3.2

Packaging Details: T&R

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 3KK/Month

Get Best Price

Product Details

Product Description
Highlight:

0.1Vrms Gigabit Ethernet Transformer

,

Gigabit Ethernet Transformer 100KHz

,

HST-24056SXCR Transformer

Specifications:
HST-24056SXCR
Mounting:
SMT
Ethernet:
1x 10/100/1000Mbps
Samples:
Available
Archivi Disponibili:
PDF/3D/ISG/Stp/Step/Datasheet
Specifications:
HST-24056SXCR
Mounting:
SMT
Ethernet:
1x 10/100/1000Mbps
Samples:
Available
Archivi Disponibili:
PDF/3D/ISG/Stp/Step/Datasheet
HST-24056SXCR 0.1Vrms Gigabit Ethernet Transformer 100KHz
HST-24056SXCR Gigabit Magnetic Transformers Ethernet Isolated Filter



Features:
● Compliant with IEEE 802.3 standard for 1000 BASE-T
● Suitable for PoE applications(350mA@48V continouos).
● Primary inductance(Lp)350uH min.@ 100KHz,0.1Vrms,8mA
● LL:0.5uH Max @100KHz, 0.1V
● Cww:30pF Max@100KHz, 0.1V
● Primary DCR:0.9ΩMax;Secondary DCR:1.2ΩMax.
● Designed for reflow soldering at temperatures up to 260℃ .
● Storeage Temperature -25℃ to +125℃.
● RoHS compliance



Tags:

100Base-T Transformer,

Gigabit Ethernet Transformer,

Power Over Ethernet Transformer
