HST-4095SCR 350uh Min 1500Vrms Ethernet Lan Transformer HST-4096SCR HST-4097SCR

HST-4095SCR 350uh Min 1500Vrms Ethernet Lan Transformer HST-4096SCR HST-4097SCR
HST-4095SCR 350uh Min 1500Vrms Ethernet Lan Transformer HST-4096SCR HST-4097SCR HST-4095SCR 350uh Min 1500Vrms Ethernet Lan Transformer HST-4096SCR HST-4097SCR

Large Image :  HST-4095SCR 350uh Min 1500Vrms Ethernet Lan Transformer HST-4096SCR HST-4097SCR

Product Details:
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: HST-4095SCR HST-4096SCR HST-4097SCR
Payment & Shipping Terms:
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Detailed Product Description
Main Customer: TI Samsung Cisco Siemens... Part Number: HST-4095SCR HST-4096SCR HST-4097SCR
TX/RX: 1CT:1CT Speed: 10/100 Base-tx
Hi-pot: 1500Vrms OCL: 350uh Min
Archivi Disponibili: PDF/3D/ISG/Stp/Step/Datasheet
High Light:

1500Vrms Ethernet Lan Transformer

,

350uh Min Ethernet Lan Transformer

,

HST-4097SCR Transformer

HST-4095SCR Single Port Ethernet Lan Transformer HST-4096SCR HST-4097SCR



● Compliant with IEEE 802.3 standard for 1000Base-T.
● Primary including 350uH@100KHz 100mV 8mA DC Bias.
● Capacitance between winding: 35pF Max at 100KHz, 1V.
● Leakage indutance 0.5uH Max at 100KHz, 0.1V.
● Designed for reflow soldering at temperatures up to 260℃.
● Storeage temperature -25℃ to +125℃.



Description:

Single Port 10/100 Base-tx Ethernet Magnetics Transformers Modules

Application LAN ETHERNET(NON PoE)
AutomDX YES
Comment HST-4095SCR HST-4096SCR HST-4097SCR
Configuration RX T,C
Configuration TX T,C
Construction TRANSFER MOLD
Cores Per Port 16
Number of Ports QUAD
PCB NO PCB
Package SMT
Package Height (mm) 5.25
Package Length (mm) 28.10
Package Width (mm) 12.00
RoHS Compliant YES-RoHS-6
Speed 10/100 BASE-TX
Temperature 0 TO 70℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT
Main P/N LP1102NL



Applications:

Used for networking and communication equipments such as HUB, PC card,Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem
