TG5G-HP10NZ5LF 24Pin 5G Base-T 1A POE Transformer Modules

Product Details

Place of Origin: Guangdong,China

Brand Name: LINK-PP

Certification: UL,RoHS,Reach,ISO

Model Number: TG5G-HP10NZ5LF

Payment & Shipping Terms

Minimum Order Quantity: 400/2000/10K/25K

Price: $0.06-$3.2

Packaging Details: T&R

Delivery Time: Stock

Payment Terms: TT,NET30/60/90 Days

Supply Ability: 3KK/Month

Get Best Price
Highlight:

1A POE Transformer Modules

,

5G Base-T POE Transformer Modules

,

TG5G-HP10NZ5LF POE Transformer Modules

Specification:
TG5G-HP10NZ5LF
Updated PN:
LP72426ANL
Speed:
5G_bit
Number Of Ports:
Single
Application:
Lan Ethernet(PoE+)
Package:
SMD
PIN Number:
24
Temperature:
0 To +70℃
Archivi Disponibil:
PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters
Lifecycle::
More Than 20Years
Specification:
TG5G-HP10NZ5LF
Updated PN:
LP72426ANL
Speed:
5G_bit
Number Of Ports:
Single
Application:
Lan Ethernet(PoE+)
Package:
SMD
PIN Number:
24
Temperature:
0 To +70℃
Archivi Disponibil:
PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters
Lifecycle::
More Than 20Years
TG5G-HP10NZ5LF 24Pin 5G Base-T 1A POE Transformer Modules

TG5G-HP10NZ5LF 24Pin 5G Base-T 1A POE Transformer Modules


Detailed Information:

TG5G-HP10NZ5LF 24Pin 5G Base-T 1A POE Transformer Modules
LINK-PP Part Number LP72426ANL
Speed 5G BASE-T
Number of Ports SINGLE
Application - LAN ETHERNET (PoE+)
Package SMD
Temperature 0 to +70℃
AutomDX YES
Comment SAME AS NL VERSION
Configuration RX C,T
Configuration TX C,T
Construction OPEN FRAME
Cores Per Port 8
Number of Ports SINGLE
Package Height (Inches) 0.236
Package Height (mm) 6.00
Package Length (Inches) 0.715
Package Length (mm) 18.15
Package Width (Inches) 0.630
Package Width (mm) 16.00
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT


TG5G-HP10NZ5LF 24Pin 5G Base-T 1A POE Transformer Modules 0



You may be interesting in below considerate supports:
Datasheet Request by email to contact us
Samples Free For Free samples delivery, pls advise below infomation For Shipping
Company Name
Delivery Address
Telephone Number
Contact Person
UPS/DHL/Fedex/TNT A.C (If available)
Trial Production U/P(USD) $0.06-$3.2 We can ship out parts directly to your warehouse/door to door
L/T(Weeks) Stock
Shipping Term DAP/CIF/FCA/FOB
Mass Production U/P(USD) Stock
L/T(Weeks) Stock
Shipping Term DAP/CIF/FCA/FOB
Lifecycel More than 20 years You can use our parts for long term consideration
Reject Ratio Zero Defective (100% Tested)
Special Services Accept customized service Accept revised designing

Now you can contact us instantly



Reel Package : SPQ/750pcs, Qty-carton/4500pcs, Carton size/37*37*25cm, G.W-carton/7kg

TG5G-HP10NZ5LF 24Pin 5G Base-T 1A POE Transformer Modules 1

Feature:

10/100 BASE-T MAGNETICS MODULES P/N: H2001DG DATASHEET
●Dual Port transformer Modules (10/100 Base-TX) for Auto MDI/MDIX applications.
●Compatible with IEEE 802.3 and ANSI X3.236 standard
including baseline wander compensation specification OF
350uH OCL when Biased at 8mA from 0℃ ℃ to 70 ℃.
●Availiable in Through Hole package.
●Operating Temperature range: 0℃ ℃ to +70 ℃
●Storage temperature range: -25℃ ℃ to +125 ℃



Electrical Specifications @ 25°C

1.Turns Ratio:
TX=1CT∶1CT RX=1CT∶1CT
2.Pri OCL: 350uH MIN
@100KHz,0.1V,8mADC Bias.
3.Insertion Loss:
1-100MHz:-1.15dB MAX
4.Return Loss(dB MIN):
1-30MHz:-18 30-60MHz:-14
60-80MHz:-12
5.Crosstalk:
1-100MHz:-38dB MIN
6.CMRR: 1-100MHz:-40dB TYP
7.Hi-Pot: 1500Vrms @0.5mA
8.Operating Temperature: 0℃~70℃/-40℃~+85℃
