Model Number: TG110-AE050N5LF
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Part Number: |
TG110-AE050N5LF |
Turns Ratio: |
1CT:1CT (Transmitter & Receiver) |
Data Rate: |
10/100 Mbps |
Mounting Type: |
Surface Mount |
Package: |
SMD-16 |
Cw/w (Interwinding Cap): |
35pF Max |
DCR (DC Resistance): |
0.9Ω Max |
Isolation Voltage: |
1500Vrms |
Operating Temperature: |
-40°C To +85°C |
Dimensions (L X W X H): |
12.70mm X 7.11mm X 6.35mm |
Part Number: |
TG110-AE050N5LF |
Turns Ratio: |
1CT:1CT (Transmitter & Receiver) |
Data Rate: |
10/100 Mbps |
Mounting Type: |
Surface Mount |
Package: |
SMD-16 |
Cw/w (Interwinding Cap): |
35pF Max |
DCR (DC Resistance): |
0.9Ω Max |
Isolation Voltage: |
1500Vrms |
Operating Temperature: |
-40°C To +85°C |
Dimensions (L X W X H): |
12.70mm X 7.11mm X 6.35mm |
If your design needs a compact, automotive-grade Ethernet magnetics solution for 10/100BASE-TX links, TG110-AE050N5LF offers the right mix of size, compliance, and electrical performance. The part is specified as AEC-Q200 qualified, UL/EN60950 recognized, and 100% compliance tested, with patented open frame construction for robust integration in high-reliability designs.
| Parameter | Specification |
|---|---|
| Product Number | TG110-AE050N5LF |
| Type | LAN Isolation Transformer |
| Mounting Type | Surface Mount (SMD) |
| Qualification | AEC-Q200 |
| Grade | Automotive |
| Application | Single Port 10/100BASE-TX Automotive Ethernet |
| Number of Channels | Single |
| Data Rate | 10/100 Mbps |
| Turns Ratio | 1CT:1CT |
| OCL (Min) | 350 µH |
| Cw/w (Max) | 35 pF |
| DCR (Max) | 0.9 Ω |
| Hi-Pot Isolation | 1500 Vrms |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Package / Case | SMD-16 |
| Length | 12.70 mm |
| Width | 7.11 mm |
| Height | 6.35 mm |
| Compliance | UL/EN60950 Recognized, 100% Compliance Tested |
| Construction | Patented Open Frame Construction |
Precision engineering allows the TG110-AE050N5LF to maintain a small profile without sacrificing performance:
The TG110-AE050N5LF is specifically designed for high-reliability sectors, including:
For engineers and sourcing teams, the TG110-AE050N5LF stands out because it combines automotive qualification with practical Ethernet transformer performance. Its AEC-Q200 qualification, wide temperature range, and 1500Vrms isolation help support durable system-level designs in automotive environments.
It is a single-port 10/100BASE-TX automotive LAN transformer designed for automotive infotainment and related Ethernet isolation applications.
Yes. It is listed as AEC-Q200 and automotive grade.
The specified operating range is -40°C to +85°C.
The transformer is rated at 1500Vrms hi-pot.
It uses an SMD-16 package with overall dimensions of 12.70 mm × 7.11 mm × 6.35 mm.
