Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: HF-81606T
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Part Number: |
HF-81606T |
Application: |
10/100Base-T |
Package: |
SMD |
PIN Number: |
16 |
Datasheet: |
Cross LP1188NL |
Operating Temp. Range: |
–40 °C ~ +85 °C |
Part Number: |
HF-81606T |
Application: |
10/100Base-T |
Package: |
SMD |
PIN Number: |
16 |
Datasheet: |
Cross LP1188NL |
Operating Temp. Range: |
–40 °C ~ +85 °C |
The HF-81606T is a 16-pin surface-mount (SMD) Ethernet isolation transformer module designed for 10/100Base-T applications.
It provides signal coupling, impedance matching, and galvanic isolation between the Ethernet PHY and the twisted-pair network cable.
Engineered for superior electrical performance and long-term reliability, the HF-81606T ensures excellent EMI suppression, low insertion loss, and high common-mode rejection in compact LAN systems. 100% Cross LINK-PP LP1188NL LAN Magnetics.
This transformer module is widely used in Ethernet switches, routers, PC motherboards, NIC cards, IP phones, and xDSL modems.
| Parameter | Condition / Frequency | Typical / Min. Value |
|---|---|---|
| Data Rate | — | 10/100 Mbps |
| Turns Ratio (Chip:Line) | — | 1CT : 1CT |
| Inductance (per winding) | 100 kHz, 0.1 V, 12 mA DC bias | ≥ 350 µH |
| Insertion Loss | 1–100 MHz | ≤ 1.4 dB |
| Return Loss | 1–30 MHz / 40 MHz / 100 MHz | ≥ 16 / 14.4 / 10 dB |
| Crosstalk (Between Channels) | 30 MHz | ≥ –40 dB |
| Differential-to-Common Mode Rejection | 30 MHz / 100 MHz | ≥ 45 / 35 dB |
| Hi-Pot (Isolation Voltage) | — | 1500 Vrms |
| Operating Temperature | — | –40 °C ~ +85 °C |
| Storage Temperature | — | –40 °C ~ +125 °C |
