SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules

China SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules supplier
SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules supplier SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules supplier SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules supplier

Large Image :  SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO,UL,Reach,SGS,RoHS
Model Number: SM51589L

Payment & Shipping Terms:

Minimum Order Quantity: 1000/5000
Price: Supportive
Packaging Details: Reel Package
Delivery Time: Stock
Payment Terms: T/T, Western Union
Supply Ability: 3000K/month
Contact Now
Detailed Product Description
Spec: LP5006ANL Spec2: SM51589PEL
Mounting: SMD Type: Transformer Isolation
Samples: Free Ethernet: 1GE POE

SM51589L , SM51589PEL LAN 10/100/1000 Base-T Transformer (PoE) Modules



Features
■ Compliant with IEEE802.3 standards
■ Designed for 10/100/1000 Base-T and PoE
■ 1500 VDC dielectric withstanding voltage
■ RoHS compliant*

SM51589L / SM51589PEL LAN Transformer 10/100/1000 Base - T PoE Modules

Turns Ratio TX/RX....................1CT:1CT
Cross Talk
30 MHz ...............................45 dB min.
60 MHz ...............................40 dB min.
80 MHz ...............................35 dB min.
Insertion Loss
1-100 MHz .......................-1.0 dB max.
Return Loss (@ 100 Ohms)
1-30 MHz ............................18 dB min.
40 MHz ............................14.4 dB min.
50 MHz ............................13.1 dB min.
60-80 MHz ..........................12 dB min.
100 MHz .............................10 dB min.
PRI OCL (@100 KHz,
0.1 V, 8 mA, DC Bias) ..... 350 μH min.
DCMR
30 MHz ...............................43 dB min.
60 MHz ...............................37 dB min.
80 MHz ...............................33 dB min.
PoE Current .................Up to 600 mADC
for 1000 Base-T
Isolation Hi-Pot ...........1500V, 1 mA,
2 seconds
Operating Temperature
..................................-40 °C to +85 °C
