Product Details
Place of Origin: China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: HFJV1-1G01RL
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000
Price: $0.09-$3.85
Packaging Details: 50pcs/tray,1200pcs/carton
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 4200K-PCS/Month
Original: |
HFJV1-1G01RL |
Equivalent: |
LPJD0713DNL |
Operating Temperature: |
0 To 70ºC |
Samples: |
Free Available |
PHY Drive: |
Current |
Lifecycle: |
More Than 20Years |
Original: |
HFJV1-1G01RL |
Equivalent: |
LPJD0713DNL |
Operating Temperature: |
0 To 70ºC |
Samples: |
Free Available |
PHY Drive: |
Current |
Lifecycle: |
More Than 20Years |
The HALO HFJV1-1G01RL is a single-port, vertical, magnetic RJ-45 jack designed for Gigabit Ethernet (10/100/1000 Base-T) applications. It belongs to HALO Electronics’ FastJack series of modular connectors.
Typical applications include networking equipment, routers, switches, embedded devices, and other board-mounted Ethernet interfaces that require high-speed connectivity and integrated magnetics.
| Parameter | Value / Description |
|---|---|
| Halo Part Number | HFJV1-1G01RL |
| LINK-PP Part Number | LPJD0713DNL |
| Ports | 1 × RJ-45 (8P8C) |
| Mounting style | Through-hole (vertical) |
| Network speed | 10/100/1000 Base-T |
| Contact plating | ≥ 30 µin gold |
| Operating temperature | 0 °C to +70 °C (standard) |
| Board height | Approx. 16.51 mm (0.650") |
| Dimensions (L×W) | ≈ 21.59 mm × 16.00 mm |
| UL rating | Housing material: UL94V-0 |
| Shielding |
Yes – metal shell, EMI tabs |
The HFJV1-1G01RL is engineered to meet Gigabit Ethernet signal integrity requirements, ensuring stable data transmission across the full operating frequency range.
Return Loss (Minimum)
| Frequency Range | Return Loss |
|---|---|
| 1–40 MHz | ≥ -18 dB |
| 60 MHz | ≥ -14 dB |
| 80 MHz | ≥ -12 dB |
| 100 MHz | ≥ -10 dB |
PHY Drive Type: Current Drive
This makes the HFJV1-1G01RL compatible with a wide range of modern Ethernet PHY chipsets used in switches, routers, and embedded systems.
| HFJV1-1G01RL | HFJV1-1G01-L11RL | HFJV1-1G01-L12RL |
| HFJV1-1G06RL | HFJV1-1G06-L11RL | HFJV1-1G06-L12RL |
| HFJV1-1G11RL | HFJV1-1G11-L11RL | HFJV1-1G11-L12RL |
The HFJV1-1G01RL Gigabit MagJack is widely used in:
