Product Details
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: JX3V-9010NL/JX3V-9010NLT
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.09-$1.85
Packaging Details: 60pcs/Tray; 22 trays/carton
Delivery Time: 1-2 Weeks
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 6000000/Month
Number Of Ports: |
1X1 |
Data Rate: |
100Base-T |
Mounting: |
THR (Pin-in-Paste) |
Entry: |
Top Entry |
Mount Style: |
Vertical Mount |
PoE: |
NONE |
LED/Light Pipe: |
Green & Yellow |
EMI / Gasket: |
Without |
Number Of Ports: |
1X1 |
Data Rate: |
100Base-T |
Mounting: |
THR (Pin-in-Paste) |
Entry: |
Top Entry |
Mount Style: |
Vertical Mount |
PoE: |
NONE |
LED/Light Pipe: |
Green & Yellow |
EMI / Gasket: |
Without |
JX3V-9010NL/JX3V-9010NLT Vertical RJ45 Jack in the top entry form with integrated magnetics and stand-off features that support the component above the PCB to facilitate through-hole reflow processing. The JX3V Series represents the latest revision of the popular Top Entry product range and has been designed to suit the growing demand for reflow-compatible THT products for the various technologies being used:
Be it Pin-in-Paste (PiP), Solder in the Hole (SiH), Intrusive in-Hole Reflow, Through Hole Reflow (THR), or just using these products to save on placement time for a 2 stage Soldering process (IR followed by WAVE).
| Electrical Specifications @ 25°C - Operating Temperature -40°C to +85°C | ||
|---|---|---|
| LEDs | Left Green /Right Yellow | |
| Speed | 10/100Base-T | |
| EMI Tabs | N/A | |
| Insertion Loss | 1~100MHz: -2.0 (dB max) | |
| Insertion Loss | 1~30MHz: -16 (dB min) 30~60MHz: -12 (dB min) 60~80MHz: -10 (dB min) |
|
| Crosstalk |
1~10MHz: -40 (dB TYP) 32~65MHz: -35 (dB TYP) 65~100MHz: -30 (dB TYP) |
|
| Common Mode Rejection | 1~100MHz: -30 (dB TYP) | |
| HiPot | 2250VDC | |
| RJ45 Material Specification | ||
| Shield |
Material: Brass Finish: 30-50µ inches thick nickel over brass |
|
| Contact |
Material: Phosphor Bronze Plating Area: 30µ inches gold over 50µ inches nickel Solder Area: Tin matte finish over nickel |
|
| Housing |
Material: Thermoplastic Specification: UL 94 V-0 |
|
| MSL Rating | 1 | |
| Storage Temperature | -50 to +125°C | |
| LED Specifications | ||
| Emitted Color | Green | Yellow |
| Wavelength | 565nm | 590nm |
| Power Dissipation | 105nW MAX | 105nW MAX |
| DC Forward Current | 20mA MAX | 20mA MAX |
| Forward Voltage(VF) @ 20 mA | 2.2V TYP | 2.1V TYP |
