Model Number: HB3602NL
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$2.5
Packaging Details: T&R
Delivery Time: About 1-2 Days
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Part Number: |
HB3602NL |
Isolation Voltage: |
1500 VAC |
Turns Ratio: |
1CT:1CT |
Data Rate: |
100BASE-TX |
No. Of Channels: |
Dual |
Mounting Style: |
Through-Hole |
Operating Temperature: |
0/+70°C |
RoHS: |
Yes |
Part Number: |
HB3602NL |
Isolation Voltage: |
1500 VAC |
Turns Ratio: |
1CT:1CT |
Data Rate: |
100BASE-TX |
No. Of Channels: |
Dual |
Mounting Style: |
Through-Hole |
Operating Temperature: |
0/+70°C |
RoHS: |
Yes |
The HB3602NL is a dual-port 10/100Base-T Ethernet transformer module featuring a 1:1 turns ratio in a 20-pin through-hole (THD) package. Built with NPB core material and TU construction, it delivers reliable signal isolation, EMI suppression, and consistent performance for Ethernet applications.
| Parameter | Specification |
|---|---|
| Application | Ethernet Transformer |
| Supported Speed | 10/100Base-T |
| Number of Ports | Dual-port |
| Turns Ratio | 1CT:1CT (1:1) |
| Inductance | 350 µH |
| Isolation Voltage | 1.5 kVrms |
| Mounting Type | Through-Hole |
| Dimensions (L × W × H) | 25.40 mm × 10.00 mm × 6.60 mm |
| Operating Temperature | 0 °C to +70 °C |
| PoE | Non-PoE |
| RoHS Compliance | Yes (fully RoHS compliant) |
The HB3602NL Dual-Port LAN Transformer Module is designed for 10/100Base-T Ethernet and provides signal isolation, EMI suppression, and reliable data transmission. Typical applications include:
