Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: TLA-8T104WLF-T
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.08-$1.2
Packaging Details: T&R
Delivery Time: in Stock Ship Today
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Part Number: |
TLA-8T104WLF-T |
Products Type: |
Ethernet Transformers |
Inductance: |
350µH |
Turns Ratio: |
1CT:1CT |
Isolation Voltage: |
1500Vrms |
Operating Temperature Range: |
-40°C To +85°C |
Part Number: |
TLA-8T104WLF-T |
Products Type: |
Ethernet Transformers |
Inductance: |
350µH |
Turns Ratio: |
1CT:1CT |
Isolation Voltage: |
1500Vrms |
Operating Temperature Range: |
-40°C To +85°C |
The TDK TLA-8T104WLF-T is a high-performance SMT transformer module designed for LAN 10G Base-T applications. Engineered specifically for automotive electronic systems, it ensures reliable high-speed data transmission while meeting the stringent AEC-Q200 qualification standard. With excellent isolation, low insertion loss, and compact dimensions, this module is ideal for next-generation automotive Ethernet networks and other demanding high-speed communication environments.
| Parameter | Specification |
|---|---|
| Type | LAN 10G Base-T Pulse Transformer |
| Inductance | 350 µH (100 kHz, 8 mA DC bias) |
| Turns Ratio | 1CT:1CT (TX and RX channels) |
| Insertion Loss | ≤ 1 dB (0.1 - 100 MHz) |
| Interwinding Capacitance | ≤ 30 pF |
| Isolation Voltage | 1500 Vrms, 50 Hz, for 1 minute |
| Operating Temperature | -40°C to +85°C |
| Package Type | Surface-mount, 11.60 × 6.50 × 5.90 mm |
| Packaging | Tape & reel (1000 pcs per reel) |
| Compliance | RoHS and REACH SVHC-Free |
