Surface Mount 7490200110 Discrete Single Port Gigabit 24 Pins Magnetics

China Surface Mount 7490200110 Discrete Single Port Gigabit 24 Pins Magnetics supplier
Surface Mount 7490200110 Discrete Single Port Gigabit 24 Pins Magnetics supplier Surface Mount 7490200110 Discrete Single Port Gigabit 24 Pins Magnetics supplier Surface Mount 7490200110 Discrete Single Port Gigabit 24 Pins Magnetics supplier Surface Mount 7490200110 Discrete Single Port Gigabit 24 Pins Magnetics supplier Surface Mount 7490200110 Discrete Single Port Gigabit 24 Pins Magnetics supplier

Large Image :  Surface Mount 7490200110 Discrete Single Port Gigabit 24 Pins Magnetics

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO,UL,Reach,SGS,RoHS
Model Number: 7490200110

Payment & Shipping Terms:

Minimum Order Quantity: 1000
Price: Supportive
Packaging Details: Reel Package
Delivery Time: Stock or 3 weeks
Payment Terms: Paypal , T/T, Western Union
Supply Ability: 3000000/Month
Contact Now
Detailed Product Description
Specification: 7490200110 P.N: LP82440NL
Family: Ethernet Magnetic Transformer Mounting: Surface Mounting
Pins: 24 Pins Samples: Free Available
Archivi Disponibili: PDF/3D/ISG/Stp/Step/Datasheet

Surface Mount 7490200110 Discrete Single Port Gigabit 24Pins Magnetics



7490200110
Trader Part Number
7490200110
Price Break
Unit Price
Extended Price
1-5
A
-
10-50
B
-
100-500
C-1
-
1,000-2,500
Supportive
-
5,000
Dynamic
Dynamic
10,000
Dynamic
Dynamic
50,000
 Negotiable
Negotiable
100,000
 Negotiable
Negotiable
500,000
 Negotiable
Negotiable
Made in China
SM-LP82440NL
Manufacturer
LINK-PP China
Description
Ethernet Transformer Modules
Documents Available
PDF/3D/Step/IGS/Price/Cross
Quantity Available
2,000 PCS or 4 weeks



7490200110 Product Features:

Electrical Specifications @25℃
1.Turn Ratio(TX/RX):
  Pri:Sec=1CT:1CT ±5%P2.Inductance OCL: 350uH Min
  @100KHz/0.1V 8mA DC BLAS
3.Insertion Loss:
  1-100MHz:-1.0dB Max
4.Return Loss:
  1-30MHz:-18dB Min
  40MHz:-14.4dB Min
  50MHz:-13.1dB Min
  60-80MHz:-12dB Min
5.Crosstalk:
  30MHz:-45dB Min
  60MHz:-40dB Min
  100MHz:-35dB Min
6.DCMR:
  30MHz:-40dB Min
  60MHz:-35dB Min
  100MHz:-30dB Min
7.Isolation Voltage: 1500Vrms
8.Operating Temperature: 0℃~70℃

Surface Mount 7490200110 Discrete Single Port Gigabit 24 Pins Magnetics

Surface Mount 7490200110 Discrete Single Port Gigabit 24Pins
