RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS

China LINK-PP INT'L TECHNOLOGY CO., LIMITED certification
China LINK-PP INT'L TECHNOLOGY CO., LIMITED certification
WOW , 100% Tested ,Zero Defective

—— TI

LINK-PP is Our Best Supplier in China

—— Intel

Thanks a Lot For Supplying Excellent RJ45 And Transformer ,LINK-PP Deserve the Consideration Worldwidely

—— Cisco

LINK-PP is Flex type A Vendor For All RJ45 Connector and Transformer

—— Flextronics

I'm Online Chat Now

RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS

RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS
RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS

Large Image :  RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS

Product Details:
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: ISO9001,SGS,UL,CE,REACH
Model Number: RJHSE-5385-02
Payment & Shipping Terms:
Minimum Order Quantity: 50/500/1000/25K
Price: $0.11-$12
Packaging Details: Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 208K/Month
Detailed Product Description
Part No: RJHSE-5385-02 Category: Cat5/5e
Mounting: Thru-hole Termination: Solder
Samples: Available Archivi Disponibili: PDF/3D/ISG/Stp/Step/Datasheet
High Light:

multi port connector

,

modular jacks rj45

RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS
  • 2x Rj45 8P8C
  • R/A Shield Connector
  • 1.3U,3U,6u,15,30u,50u Gold Plating
  • 1x2 Dual Port Ethernet Port
  • RJHSE-5385-02 Cross LPJE201AWNL
1X2 Cat5 8P8C RJ45 Female Connector without Integrated Magnetics , WITHOUT LED,Tab Down,RoHS
Amphenol Part Number RJHSE-5385-02
Application-Lan ETHERNET(NoN PoE)
AutomDX YES
Bst Circuit YES
Configuration RX T,C
Configuration TX T,C
Contact Mating Area Plating GOLD 6u"/15u"/30u"
Cores per Port NO
Diodes NO DIODES
LED Option Green/Green
Latch TAB Up
Number of Ports 1X2
PCB FR4
PCB Mount Angle SIDE ENTRY
PCB Retaining Post T POST
Package Height (Inches) 0.516
Package Height (mm) 13.10
Package Length (Inches) 0.620
Package Length (mm) 15.75
Package Width (Inches) 1.270
Package Width (mm) 32.25
Pin Type THT SOLDER
RoHS Compliant YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search YES
Shield EMI Tabs WITH
Performance Category Cat5
Temperature -40 TO + 85℃
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT
LINK-PP Part Number LPJE201AWNL

RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS 0

RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS 1

RJHSE-5385-02 2x rj45 Connector Dual port, 8P8C R/A Shield W/LED,Side Entry RoHS 2
