Product Details
Place of Origin: GuangDong, China
Brand Name: LINK-PP
Certification: UL,ROHS,Reach,ISO
Model Number: JXD2-0010NL
Payment & Shipping Terms
Minimum Order Quantity: 50/500/1000/25K
Price: $0.09-$1.85
Packaging Details: 60PCS/Tray,22Trays=1320pcs/Carton=37*30*30CM=10KG
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3000000/Month
Specification: |
JXD2-0010NL |
LINK-PP Part Number: |
LPJD4012BENL |
Category: |
Rj45 Top Entry |
Interface: |
10/100Base-T |
LED Option: |
Flexible Designed |
Free Samples: |
Available |
Specification: |
JXD2-0010NL |
LINK-PP Part Number: |
LPJD4012BENL |
Category: |
Rj45 Top Entry |
Interface: |
10/100Base-T |
LED Option: |
Flexible Designed |
Free Samples: |
Available |
|
|
Electrical Specification:
TEST NOTES(25±5℃)
1.TR:(100KHZ,0.1V);
TX=1:1±2% RX=1:1±2%
2.LX:(100KHZ,100mV,8mA,DC Bias)
PINS:(R1-R3),(R4-R6)=350uH MIN
3. Transmitter filter & Receiver Filter Type:
Balance low pass 100 Ω impedance
4. HIPOT:
Input(R1-R3)TO Output(C1-C2):1500VAC 60sec
Input(R4-R6)TO Output(C3-C6):1500VAC 60sec
5. INSERTION LOSS:
-1.0dB MAX @ 1.0MHz TO 100MHz
6. RETURN LOSS:
-18dB MIN @ 1.0MHz TO 30MHz
-16dB MIN @ 30MHz TO 60MHz
-12dB MIN @ 60MHz TO 80MHz
7. CROSS TALK:
-30dB MIN @1.0MHz TO 100MHz
8. COMMON MODE REJECTION:
-30dB MIN @1.0MHz TO 100MHz
9. OPERATING TEMPERATURE: -40℃～+85℃.
