Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: AFBR-79E3PZ
Payment & Shipping Terms
Minimum Order Quantity: 10/100/25K
Price: $0.11-$35
Packaging Details: 20/Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 350K/Month
Specifications: |
AFBR-79E3PZ |
Data Rate: |
10.3125 GBd |
Wavelength: |
850nm |
Maximun Distance: |
400m |
Fiber Type: |
Multimode Glass |
Emitter: |
VCSEL |
Voltage: |
3.3V |
Applications: |
Telecom/Datacom Systems |
Connector: |
MTP (MPO) |
Mounting: |
Pluggable,QSFP+ |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
1(Unlimited) |
Specifications: |
AFBR-79E3PZ |
Data Rate: |
10.3125 GBd |
Wavelength: |
850nm |
Maximun Distance: |
400m |
Fiber Type: |
Multimode Glass |
Emitter: |
VCSEL |
Voltage: |
3.3V |
Applications: |
Telecom/Datacom Systems |
Connector: |
MTP (MPO) |
Mounting: |
Pluggable,QSFP+ |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
1(Unlimited) |
| Specifications: | AFBR-79E3PZ |
| LINK-PP Part Number: | LPXXXXXX |
| Product Class: | Fiber Optics |
| Product Family: | Optical Transceivers |
| Product Series: | QSFP+ |
| Product Name: | QSFP+ Optical Transceivers |
| Status Available: | Active |
| RoHS: | RoHS-6 Compliance |
|
Specifications:
|
|
|
Data Rate: |
10.3125 GBd |
| Wavelength: | 850nm |
| Maximun Distance: | 400m |
| Fiber Type: | Multimode Glass |
| Emitter: | VCSEL |
| Voltage-Supply: | 3.3V |
| Applications: | Telecom/Datacom Systems |
| Connector Type: | MTP (MPO) |
| Mounting Type: | Pluggable,QSFP+ |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level(MSL): | 1(Unlimited) |
|
Feature Description:
|
● Compliant to the 40GbE IEEE 802.3ba-2010 specifications (40GBASE-SR4 and XLPPI) and the IEEE 802.3ae 10GBASE-SR optical specification on per channel basis with extended mean laser optical power
● Supports optical interoperability up to 300m OM3 (400m OM4) MMF with IEEE 802.3ae 10GBASE-SR compliant modules that can manage receiving optical power up to +1 dBm.
● Power level 1: max power < 1.5 W
● Pull tab: ease of transceiver insertion and extraction; tab color coded "Orange" for 3SR4 identification
● 0 to +70°C case temperature operating range
● Hot pluggable transceiver for servicing and ease of installation
● Utilizes a standard 12/8 lane optical fiber with MTP (MPO) optical connector for high density and thin, light-weight cable management.
