Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: AFBR-57D7APZ
Payment & Shipping Terms
Minimum Order Quantity: 10/100/25K
Price: $0.11-$35
Packaging Details: 20/Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 350K/Month
Specifications: |
AFBR-57D7APZ |
Data Rate: |
8.5Gbps |
Wavelength: |
850nm |
Maximun Distance: |
- |
Fiber Type: |
Singlemode Glass |
Emitter: |
DWDM EML |
Voltage: |
3.3V |
Applications: |
General Purpose |
Connector: |
LC Duplex |
Mounting: |
Pluggable,SFP |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
1 (Unlimited) |
Specifications: |
AFBR-57D7APZ |
Data Rate: |
8.5Gbps |
Wavelength: |
850nm |
Maximun Distance: |
- |
Fiber Type: |
Singlemode Glass |
Emitter: |
DWDM EML |
Voltage: |
3.3V |
Applications: |
General Purpose |
Connector: |
LC Duplex |
Mounting: |
Pluggable,SFP |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
1 (Unlimited) |
| Specifications: | AFBR-57D7APZ |
| LINK-PP Part Number: | LPXXXXXX |
| Product Class: | Fiber Optics |
| Product Family: | Optical Transceivers |
| Product Series: | SFP |
| Product Name: | SFP Optical Transceivers |
| Status Available: | Active |
| RoHS: | RoHS-6 Compliance |
|
Specifications:
|
|
|
Data Rate: |
8.5 Gbps |
| Wavelength: | 850nm |
| Maximun Distance: | - |
| Fiber Type: | Singlemode Glass |
| Emitter: | DWDM EML |
| Voltage-Supply: | 3.3V |
| Applications: | General Purpose |
| Connector Type: | LC Duplex |
| Mounting Type: | Pluggable,SFP |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Moisture Sensitivity Level(MSL): | 1(Unlimited) |
|
Feature Description:
|
• Compliant to Restriction on Hazardous Substances (RoHS) directive
• Rate Select not required
• Diagnostic features per SFF-8472 “Diagnostic Monitoring Interface for Optical Transceivers”
• Real time monitoring of:
– Transmitted optical power
– Received optical power
– Laser bias current
– Temperature
– Supply voltage
• SFP Plus Mechanical Applications
• Wide temperature and supply voltage operation (-10°C to 85°C) (3.3 V ± 10%)
• Transceiver specifications per SFP (SFF-8074i) MultiSource Agreement and SFF-8472 (revision 10.0)
– 8.5 GBd Fibre Channel operation for FC-PI-4 800-M5-SN-S, 800-M6-SN-S and 800-M5E-SN-I
– 4.25 GBd Fibre Channel operation for FC-PI 400-M5-SN-I , 400-M6-SN-I and 400 M5E-SN-I
– 2.125 GBd Fibre Channel operation for FC-PI 200-M5-SN-I , 200-M6-SN-I and 200 M5E-SN-I
• Link lengths at 8.5 GBd: 21m with 62.5um OM1, 50m with 50um OM2, 150m with 50um OM3
• Link lengths at 4.25 GBd: 70m with 62.5um OM1, 150m with 50um OM2, 380m with 50um OM3
• Link lengths at 2.125 GBd: 150m with 62.5um OM1, 300m with 50um OM2, 500m with 50um OM3
• LC Duplex optical connector interface conforming to ANSI TIA/EIA604-10 (FOCIS 10A)
• 850 nm Vertical Cavity Surface Emitting Laser (VCSEL) source technology
• IEC 60825-1 Class 1/CDRH Class 1 laser eye safe
• Enhanced EMI performance for high port density applications
