Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: AFBR-57F5UMZ
Payment & Shipping Terms
Minimum Order Quantity: 10/100/25K
Price: $0.11-$35
Packaging Details: 20/Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 350K/Month
Specifications: |
AFBR-57F5UMZ |
Data Rate: |
4.25~14.024Gbps |
Wavelength: |
850nm |
Maximun Distance: |
- |
Fiber Type: |
- |
Emitter: |
FP Laser |
Voltage: |
3.3V |
Applications: |
Fibre Channel Links |
Connector: |
LC Duplex |
Mounting: |
Pluggable,SFP+ |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
1 (Unlimited) |
Specifications: |
AFBR-57F5UMZ |
Data Rate: |
4.25~14.024Gbps |
Wavelength: |
850nm |
Maximun Distance: |
- |
Fiber Type: |
- |
Emitter: |
FP Laser |
Voltage: |
3.3V |
Applications: |
Fibre Channel Links |
Connector: |
LC Duplex |
Mounting: |
Pluggable,SFP+ |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
1 (Unlimited) |
| Specifications: | AFBR-57F5UMZ |
| LINK-PP Part Number: | LPXXXXXX |
| Product Class: | Fiber Optics |
| Product Family: | Optical Transceivers |
| Product Series: | SFP+ |
| Product Name: | SFP+ Optical Transceivers |
| Status Available: | Active |
| RoHS: | RoHS-6 Compliance |
|
Specifications:
|
|
|
Data Rate: |
4.25~14.024 Gbps |
| Wavelength: | 850nm |
| Maximun Distance: | - |
| Fiber Type: | - |
| Emitter: | FP Laser |
| Voltage-Supply: | 3.3V |
| Applications: | Fibre Channel Links |
| Connector Type: | LC Duplex |
| Mounting Type: | Pluggable,SFP+ |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Moisture Sensitivity Level(MSL): | 1(Unlimited) |
|
Feature Description:
|
• Compliant to RoHS directives
• 850nm Vertical Cavity Surface Emitting Laser (VCSEL)
• Class 1 eye safe per IEC60825-1 and CDRH
• Wide temperature range (0°C to 70°C)
• LC duplex connector optical interface conforming to ANSI TIA/EIA604-10 (FOCIS 10A)
• Diagnostic features per SFF-8472 “Diagnostic Monitoring Interface for Optical Transceivers”
• Enhanced operational features including EWRAP,OWRAP and variable electrical EQ/emphasis settings
• Real time monitoring of:
- Transmitter average optical power
- Received average optical power
- Laser bias current
- Temperature
- Supply Voltage
• SFP+ mechanical specifications per SFF-8432
• SFP+ compliant low speed interface
• Fibre Channel FC-PI-5 compliant high speed interface
- 1600-SN-M6-S, 800-SN-M6-S, 400-SN-M6-I
- 1600-SN-M5-S, 800-SN-M5-S, 400-SN-M5-I
- 1600-SN-M5E-I, 800-SN-M5E-I, 400-SN-M5E-I
- 1600-SN-M5F-I, 800-SN-M5F-I, 400-SN-M5F-I
• Fibre Channel FC-PI-5 compliant optical link distances
• Interoperable with 10GE compliant transceivers @10.3125Gb/s per IEEE 802.3ae 10GBASE-SR standard and Avago’s 10G-USR transceivers up to 100m using OM3 MMF and 125m OM4 MMF
