Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: AFCT-5745PZ
Payment & Shipping Terms
Minimum Order Quantity: 10/100/25K
Price: $0.11-$35
Packaging Details: 20/Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 350K/Month
Specifications: |
AFCT-5745PZ |
Data Rate: |
2.7Gbps |
Wavelength: |
1300nm |
Maximun Distance: |
2000m |
Fiber Type: |
Singlemode Glass |
Emitter: |
FP Laser |
Voltage: |
3.1V~3.5V |
Applications: |
General Purpose |
Connector: |
LC Duplex |
Mounting: |
Pluggable,SFP |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
3 (168 Hours) |
Specifications: |
AFCT-5745PZ |
Data Rate: |
2.7Gbps |
Wavelength: |
1300nm |
Maximun Distance: |
2000m |
Fiber Type: |
Singlemode Glass |
Emitter: |
FP Laser |
Voltage: |
3.1V~3.5V |
Applications: |
General Purpose |
Connector: |
LC Duplex |
Mounting: |
Pluggable,SFP |
Environment: |
Lead Free / RoHS Compliant |
MSL: |
3 (168 Hours) |
| Specifications: | AFCT-5745PZ |
| LINK-PP Part Number: | LPXXXXXX |
| Product Class: | Fiber Optics |
| Product Family: | Optical Transceivers |
| Product Series: | SFF |
| Product Name: | SFF Optical Transceivers |
| Status Available: | Active |
| RoHS: | RoHS-6 Compliance |
|
Specifications:
|
|
|
Data Rate: |
2.7Gbps |
| Wavelength: | 1300nm |
| Maximun Distance: | 2000m |
| Fiber Type: | Singlemode Glass |
| Emitter: | FP Laser |
| Voltage-Supply: | 3.1V~3.5V |
| Applications: | General Purpose |
| Connector Type: | LC Duplex |
| Mounting Type: | Pluggable,SFP |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Moisture Sensitivity Level(MSL): | 3(168 Hours) |
|
Feature Description:
|
• RoHS-6 Compliant
• Compliant with SFF-8472, internally calibrated diagnostic monitoring for optical transceivers
- Transceiver optical output power
- Receiver average optical power
- Laser bias current
- Device temperature
- Supply voltage
• Compliant with SFF-8074i SFP transceiver specification
• Compliant with ITU-T G957 STM-16 I-16 (2km) and
S-16.1 (15km)
• Compliant with Telcordia GR253 SR (2km) and
IR-1 (15km)
• Class 1 CDRH/IEC 825 eye safety compliant
• Operating case temperature:
–10 °C to +85 °C
–40 °C to +85 °C
• Multitrate operation from 125 Mb/s to 2.7 Gb/s
• LC duplex fiber connector
• Manufactured in an ISO 9001 compliant facility
