| Specifications: | AFBR-703SNZ | Data Rate: | 10 GBd |
|---|---|---|---|
| Wavelength: | 850nm | Maximun Distance: | 300m |
| Fiber Type: | Multimode Glass | Emitter: | VCSEL |
| Voltage: | 3.3V | Applications: | Ethernet |
| Connector: | LC Duplex | Mounting: | Pluggable,SFP+ |
| Environment: | Lead Free / RoHS Compliant | MSL: | 3 (168 Hours) |
| Highlight: | fiber sfp module,fiber optic transceiver |
||
| Specifications: | AFBR-703SNZ |
| Product Class: | Fiber Optics |
| Product Family: | Optical Transceivers |
| Product Series: | SFP+ |
| Product Name: | SFP+ Optical Transceivers |
| Status Available: | Active |
| RoHS: | RoHS-6 Compliance |
|
Specifications:
|
|
|
Data Rate: |
10 Gbd |
| Wavelength: | 850nm |
| Maximun Distance: | 300m |
| Fiber Type: | Multimode Glass |
| Emitter: | VCSEL |
| Voltage-Supply: | 3.3V |
| Applications: | Ethernet |
| Connector Type: | LC Duplex |
| Mounting Type: | Pluggable,SFP+ |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Moisture Sensitivity Level(MSL): | 3 (168 Hours) |
|
Feature Description:
|
• Optical interface specifications per IEEE 802.3ae 10GBASE-SR
• Electrical interface specifications per SFF Committee SFF 8431 Specifications for Enhanced 8.5 and 10 Gigabit Small Form Factor Pluggable Module “SFP+”
• Management interface specifications per SFF Committee SFF 8431 and SFF 8472 Diagnostic Monitoring Interface for Optical Transceivers
• LC Duplex optical connector interface confirming to ANSI TIA/EA 604-10 (FOCIS 10A)
• Compliant to Restriction on Hazardous Substances (RoHS) per EU and China requirements
• Class 1 Eye safe per requirements of IEC 60825-1 /CDRH
