Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO 9001,ISO 14001,UL,SGS,REACH168
Model Number: FTGL2026P2TUN
Payment & Shipping Terms
Minimum Order Quantity: 10/100/25K
Price: $0.11-$35
Packaging Details: 20/Tray
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 350K/Month
Specifications: |
FTGL2026P2TUN |
Data Rate: |
2.48 GBd |
Wavelength: |
1490 Nm/1310 Nm |
Maximun Distance: |
40000m |
Brand: |
LINK-PP |
Emitter: |
DWDM EML |
Voltage: |
3.3V |
Applications: |
Ethernet |
Connector: |
SC |
Temperature Range: |
From -40℃ To +85℃ |
Specifications: |
FTGL2026P2TUN |
Data Rate: |
2.48 GBd |
Wavelength: |
1490 Nm/1310 Nm |
Maximun Distance: |
40000m |
Brand: |
LINK-PP |
Emitter: |
DWDM EML |
Voltage: |
3.3V |
Applications: |
Ethernet |
Connector: |
SC |
Temperature Range: |
From -40℃ To +85℃ |
Specifications: | FTGL2026P2TUN |
LINK-PP Part Number: | LPXXXXXX |
Product Class: | Fiber Optics |
Product Family: | Optical Transceivers |
Product Series: | SFP |
Product Name: | SFP Optical Transceivers |
Status Available: | Active |
RoHS: | RoHS-6 Compliance |
Specifications:
|
|
Data Rate: |
2.488 GBd |
Wavelength: | 1490nm/1310nm |
Maximun Distance: | 40000m |
Fiber Type: | Singlemode Glass |
Emitter: | DWDM EML |
Voltage-Supply: | 3.3V |
Applications: | Ethernet |
Connector Type: | RJ45 |
Temperature Range: | - 40℃ to +85℃ |
Mounting Type: | Pluggable,SFP |
Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
Moisture Sensitivity Level(MSL): | 1(Unlimited) |
Feature Description:
|
● Bi-directional transceivers operating at 2.488Gbit/s downstream,1.244 Gbit/s upstream
● Di-plexer operation at 1490 nm Tx and 1310 nm digital Rx
● Burst-mode APD receiver
● Continuous mode transmitter with DFB laser
● Built-in digital diagnostic functions
● Standard small form-factor (SFF) package with fiber pigtailed SC/UPC connector in compliant with GR326 and UL 94V0 flammability
● The pigtail comes in a tight buffer 0.9mm, 9/125/250 SMF-28 or equivalent
● Single 3.3V power supply
● Industrial operating temperature range: -40℃ to 85℃.
