749022015 Signal POE Telecom Transformer 1000 Base -T Magnetic Surface Mount

China 749022015 Signal POE Telecom Transformer 1000 Base -T Magnetic Surface Mount supplier
749022015 Signal POE Telecom Transformer 1000 Base -T Magnetic Surface Mount supplier 749022015 Signal POE Telecom Transformer 1000 Base -T Magnetic Surface Mount supplier

Large Image :  749022015 Signal POE Telecom Transformer 1000 Base -T Magnetic Surface Mount

Product Details:

Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: ISO,UL,SGS,Reach,RoHS
Model Number: 749022015

Payment & Shipping Terms:

Minimum Order Quantity: 350/1400
Price: Supportive
Packaging Details: Reel Package
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 3800000PCS/Month
Contact Now
Detailed Product Description
Specification: 749022015 Update PN: LP6096ANL
Turns Ratio: 1CT:1CT Mounting: Surface Mount
Ethernet: 1x10/100/1000Mbps Power Isolation Voltage: 1500Vrms
Capability: 720mA DC Archivi Disponibil: PDF/3D/ISG/Stp/Step/Datasheet

749022015 | LP6096ANL POE Transformer 1000Base-T Magnetic Telecom
  1. DATACOM TRANSFORMER FOR GENERAL PURPOSE APPLICATION(S)
  2. 24 SMD Magnetic+ / Transformer Power Ethernet+
  3. TRANSFORMER LAN 10/100/1000 SMD
  4. 720mA Current Ability Cross 749022015 Wurth
  5. Size / Dimension : 18.28mm L x 12.98mm W
  6. LP6096ANL Compatible to 749022015

Electrical Specification @25℃
1.Insertion Loss(dB Max):
0.1MHz: -1.2
1-125MHz: -2.0
2.Return Loss(dB Min):
1-40MHz: -16
40-100MHz: -10
3.Crosstalk(dB Min):
30MHz: -43
60MHz: -37
100MHz: -33
4.CMRR(dB Min):
30MHz: -30
200MHz: -15
5.DCR Balance: 1 Ω ±0.05Ω
6.OCL:
(1) 350uH Min @20mA DC Bias
(2) 120uH Min @30mA DC Bias
7.Temperature rise of 35℃ when supplying
800mA DC continuous over 4 pairs
8.Hipot:1500Vrms
9.Operating Temperature: -40℃~+85℃.

SPECIFICATIONS

REACH Compliant Yes
Status Active
Transformer Type DATACOM TRANSFORMER
Application SIGNAL
Approvals IEEE
Insertion Loss 1.0 dB
Manufacturer Series 749022015 & LP6096ANL
Mounting Feature SURFACE MOUNT
Operating Temperature-Min -40.0 Cel
Operating Temperature-Max 85.0 Cel
Packing Method TAPE & REEL
Physical Dimension 18.28mm x 16.25mm x 9.68mm
Primary Inductance 350.0 µH
Turns Ratio (Np:Ns) 1:1
Height 9.68 mm
Length 18.28 mm
Width 16.25 mm


NOTES:
1.Gigabit Transformer Modules With Power Over
Ethernet Option
2.Exceeds IEEE 802.3at requirements with up
to 720mA DC supply current over 2 or 4 pairs
3.For RoHS part add suffix NL
4.RoHS"NLE" peak solder rating 250℃.
