Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: 7490100110A
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Items: |
10/100 Base-T Transformer Modules |
Standard: |
IEEE 802.3u |
Turn Ratio: |
1:1 |
Mounting: |
SMT |
Ethernet: |
1x10/100Base-Tx |
Dielectric: |
1500Vrms |
Items: |
10/100 Base-T Transformer Modules |
Standard: |
IEEE 802.3u |
Turn Ratio: |
1:1 |
Mounting: |
SMT |
Ethernet: |
1x10/100Base-Tx |
Dielectric: |
1500Vrms |
| Mfr Package Description | ROHS COMPLIANT |
| REACH Compliant | Yes |
| EU RoHS Compliant | Yes |
| Status | Active |
| Transformer Type | LINK-PP Made In China |
| Application | GENERAL PURPOSE |
| Isolation Voltage | 4800 Vrms |
| Manufacturer Series | 7490100110A Cross |
| Mounting Feature | SURFACE MOUNT |
| Number of Functions | 1 |
| Operating Temperature-Min | 0.0 Cel |
| Operating Temperature-Max | 70.0 Cel |
| Primary Inductance | 350.0 µH |
| Turns Ratio (Np: Ns) | 1:1 |
| Height | 6.35 mm |
| Length | 12.70 mm |
| Width | 9.40 mm |
| Additional Feature | HEIGHT DIM INCLUDE TERMINALS ALSO |
