Product Details
Place of Origin: Guangdong,China
Brand Name: LINK-PP
Certification: UL,RoHS,Reach,ISO
Model Number: 749020111
Payment & Shipping Terms
Minimum Order Quantity: 400/2000/10K/25K
Price: $0.06-$3.2
Packaging Details: T&R
Delivery Time: Stock
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3KK/Month
Specification: |
749020111 |
Turns Ratio: |
1CT : 1CT |
Size / Dimension: |
16.50mm X 9.70mm X 2.10mm |
Hipot: |
1500V |
Samples: |
Free Available |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
Cross PN: |
LP82453NL |
Specification: |
749020111 |
Turns Ratio: |
1CT : 1CT |
Size / Dimension: |
16.50mm X 9.70mm X 2.10mm |
Hipot: |
1500V |
Samples: |
Free Available |
Archivi Disponibili: |
PDF/3D/ISG/Stp/Step/Datasheet |
Cross PN: |
LP82453NL |
|
Mfr Package Description
|
ROHS COMPLIANT
|
|
REACH Compliant
|
Yes
|
|
EU RoHS Compliant
|
Yes
|
|
China RoHS Compliant
|
Yes
|
|
Status
|
Active
|
|
Transformer Type
|
DATACOM TRANSFORMER
|
|
Application
|
LAN
|
|
Approvals
|
IEEE
|
|
Insertion Loss
|
1.0 dB
|
|
Isolation Voltage
|
1500.0 V
|
|
LINK-PP Equivalent
|
LP82453NL |
|
Manufacturer Series
|
749020111
|
|
Mounting Feature
|
SURFACE MOUNT
|
|
Number of Functions
|
4
|
|
Operating Temperature-Min
|
0.0 Cel
|
|
Operating Temperature-Max
|
70.0 Cel
|
|
Packing Method
|
TAPE & REEL
|
|
Physical Dimension
|
16.50mm X 9.70mm X 2.10mm |
|
Terminal Finish
|
Tin/Silver (Sn/Ag)
|
|
Turns Ratio (Np:Ns)
|
1CT:1CT
|
|
Height
|
2.10 mm
|
|
Length
|
16.50 mm
|
|
Width
|
9.70 mm
|
